MC58320CP

Overview

The MC58320CP is a motion controller from the Magellan 2-IC Motion Control Chipset by Performance Motion Devices. It supports three-axis control and is housed in an LQFP-144 package with SMD/SMT installation style. The device operates on a supply voltage ranging from 3 V to 3.6 V, with a maximum power supply current of 120 mA and an output current of 2 mA. It functions within a temperature range of -40°C to +85°C.

Feature Summary

• Integrated into the Magellan 2-IC Motion Control Chipset for multi-axis applications
• Supports three-axis motor control functionality
• Designed for surface mount technology (SMD/SMT) integration

Applications

• Motor control systems
• Motion control applications
• Ignition controllers

Procurement Notes

Verify the specific manufacturer part number MC58320CP against official Performance Motion Devices documentation to confirm pinout compatibility and electrical specifications. Ensure the LQFP-144 package matches the target PCB footprint. Confirm RoHS compliance status through the manufacturer's official datasheet or certification documents before procurement.

Selection Notes

Select this component when a dedicated three-axis motion controller integrated into the Magellan chipset is required. Consider the LQFP-144 package size and the 3 V to 3.6 V operating voltage range. Verify that the -40°C to +85°C industrial temperature range meets the environmental requirements of the intended application.

Part Context

This component belongs to the Motor / Motion / Ignition Controllers & Drivers product category under PMIC - Power Management ICs. It is part of the Magellan trademark family developed by Performance Motion Devices. The development kit DK58420 is associated with this chipset series.

Replacement Considerations

Consult official Performance Motion Devices documentation for confirmed substitute part numbers. No public substitutes are verified in the provided data.
