MC74113N

Overview

The MC74113N is a dual D-type flip-flop component manufactured by onsemi, belonging to the 74AC logic family. It features asynchronous Clear and Set inputs along with complementary Q and Q outputs. The device operates within a supply voltage range of 2.0V to 6.0V and supports data rates up to 50MHz at 5.0V. It is housed in a 14-pin SOIC package and is designed for high-speed digital applications requiring reliable state storage and control.

Feature Summary

• Dual D-type positive edge-triggered flip-flops with asynchronous clear and set functions
• Complementary outputs (Q and Q) for versatile logic interfacing
• High-speed operation supporting data rates up to 50MHz
• Wide operating supply voltage range from 2.0V to 6.0V

Applications

• Digital signal processing systems
• Shift registers and counters
• State machines and control logic
• Memory address latching

Procurement Notes

Verify the manufacturer marking matches onsemi specifications. Confirm the package type is 14-pin SOIC. Check for RoHS compliance documentation. Ensure the part number suffix indicates standard commercial grade unless industrial rating is required. Validate authenticity through authorized distribution channels.

Selection Notes

Select this component when dual independent D-flip-flops are needed in a compact surface-mount package. Consider the 74AC family for higher speed compared to standard 74LS. Ensure supply voltage compatibility with the 2.0V-6.0V range. Verify input/output voltage levels match system requirements.

Part Context

This component belongs to the widely used 74-series logic family, specifically the AC variant known for improved speed and power consumption characteristics. It serves as a fundamental building block in digital electronics for temporary data storage and synchronization tasks.

Replacement Considerations

Compatible substitutes include the MC74ACT113N for ACT series performance or other 74AC113 variants from different manufacturers. Ensure pinout compatibility and electrical specifications match before substitution.
