MC74HC175FL2

Flip Flops Overview

The MC74HC175FL2 is a D-Type Flip-Flop from the 74HC logic series, manufactured by onsemi. It contains four independent flip-flops within a single package. The device features positive-edge triggering and includes a master reset function. It operates with a supply voltage range of 2V to 6V. The maximum propagation delay is 22ns at 6V with a 50pF load. Static current (Iq) is 4µA. The output type is complementary. The component is housed in a 16-SOEIAJ surface-mount package.

Flip Flops Feature Summary

• Contains four independent D-type flip-flops
• Positive-edge clock triggering mechanism
• Includes a dedicated master reset input
• Complementary output configuration

Flip Flops Applications

• General-purpose digital data storage
• Shift register construction
• Register file implementation
• Timing circuit synchronization

Flip Flops Procurement Notes

Verify the specific package designation matches the required board layout, as the FL2 suffix indicates a small outline package variant distinct from standard SOIC or DIP forms. Confirm that the active status aligns with long-term production plans, as availability may fluctuate. Ensure the operating temperature range meets the environmental requirements of the final assembly. Cross-reference the manufacturer part number against official distributor catalogs to avoid counterfeit components.

Flip Flops Selection Notes

Select this component when a compact solution for quadruple D-type latching is required in space-constrained designs. The HC series offers CMOS compatibility with TTL drive capabilities. Consider the 16-SOEIAJ footprint constraints during PCB layout. Evaluate the 2V to 6V supply range against system power rails. The low static current makes it suitable for battery-powered applications where standby consumption must be minimized.

Flip Flops Part Context

This part belongs to the widely adopted 74HC family of high-speed CMOS logic devices. These components are designed for general-purpose digital applications requiring robust performance and low power consumption. The 74HC175 specifically provides quad D-type flip-flops, serving as a fundamental building block for sequential logic circuits in consumer electronics and industrial control systems.

Flip Flops Replacement Considerations

MC74HC175ADG

Flip Flops FAQ

What is the trigger edge for the MC74HC175FL2?

The device utilizes positive-edge triggering for its D-type flip-flops.

Does the MC74HC175FL2 include a reset function?

Yes, the component features a master reset input that clears all flip-flops.
