MC74HC74AFR1

Flip Flops Overview

The MC74HC74AFR1 is a dual D-type flip-flop manufactured by onsemi, featuring individual Set, Reset, and Clock inputs. It operates within a voltage range of 2.0V to 6.0V and supports a maximum clock frequency of 35 MHz. The device exhibits a maximum propagation delay of 17ns at 6V with a 50pF load. It provides complementary outputs (Q and Q-bar) and has an input capacitance of 10 pF. The component is housed in a 14-SOIC package and functions across a temperature range of -55°C to +125°C.

Flip Flops Feature Summary

• Dual D-type flip-flop architecture with asynchronous Set and Reset controls
• High-speed operation supporting up to 35 MHz clock frequency
• Wide operating voltage range from 2.0V to 6.0V for flexible system integration

Flip Flops Applications

• Digital data storage and shift register circuits
• Timing and synchronization logic in embedded systems
• State machine implementation in control applications

Flip Flops Procurement Notes

Verify the specific suffix 'FR1' against the official onsemi datasheet to confirm tape-and-reel packaging specifications and pinout compatibility. Ensure that the selected variant meets the required thermal and electrical standards for the intended application environment. Cross-reference the manufacturer part number with authorized distributors to confirm authenticity and availability status prior to procurement.

Flip Flops Selection Notes

Select this component when a dual D-flip-flop with independent set and reset functions is required in a surface-mount design. Consider the 14-SOIC package size and the 2.0V to 6.0V operating range for compatibility with existing power rails. Evaluate the 17ns propagation delay and 35MHz speed against the system timing requirements to ensure adequate performance margins.

Flip Flops Part Context

This part belongs to the 74HC series of high-speed CMOS logic devices produced by onsemi. It is functionally equivalent to other industry-standard dual D-flip-flops but offers specific packaging and performance characteristics defined by onsemi. The device is designed for use in general-purpose digital logic applications requiring reliable state retention and fast switching capabilities.

Flip Flops Replacement Considerations

Direct substitutes include MC74HC74A and MC74HC74ADG from onsemi, which share identical pinouts and logical functionality. Verify that alternative packages or suffixes maintain the same electrical parameters and operating temperature ranges before substitution.
