MC74VHC2G17MU1TCG

Overview

The MC74VHC2G17MU1TCG is a dual non-inverting buffer with Schmitt trigger inputs manufactured by onsemi. It operates within a supply voltage range of 2.0 V to 5.5 V and utilizes CMOS technology. The device features low static current of 4 µA and supports a maximum operating temperature of +125 °C. It is housed in a UDFN-6 package suitable for surface mount applications.

Feature Summary

• Dual non-inverting buffer configuration with Schmitt trigger inputs for noise immunity
• Wide operating voltage range from 2.0 V to 5.5 V
• Low power consumption with minimal static current draw

Applications

• Signal conditioning in noisy environments
• Level shifting between different logic families
• Pulse width modulation signal processing

Procurement Notes

Verify the specific suffix MU1TCG against the official datasheet to confirm package type and tape/reel specifications. Ensure compatibility with RoHS directives if required by your manufacturing standards. Cross-reference the manufacturer part number directly with authorized distributors to avoid counterfeit components.

Selection Notes

Select this component when dual buffering with hysteresis is required in compact designs. The UDFN-6 package offers space efficiency compared to larger footprints. Consider the 2.0 V minimum supply voltage for low-power portable applications where standard 5 V logic may be excessive.

Part Context

This part belongs to the MC74VHC2G series of high-speed CMOS logic devices. It shares functional similarities with other buffers but distinguishes itself through integrated Schmitt trigger inputs, which enhance signal integrity in digital circuits requiring clean transitions.

Replacement Considerations

Check for direct substitutes like MC74VHC2GT17MU1TCG if TTL-level input thresholds are needed instead of CMOS levels. Verify pinout compatibility before swapping with generic dual Schmitt trigger buffers.
