MC908JL3ECDWER

Microcontrollers Overview

The MC908JL3ECDWER is an 8-bit microcontroller from the HC08 family, manufactured by Freescale Semiconductor. It features a 4KB (4K x 8) FLASH program memory and 128 bytes of RAM. The device operates at a maximum clock speed of 8MHz with an internal oscillator. It is housed in a 20-SOIC package and supports a supply voltage range of 2.7V to 3.3V. The component includes peripherals such as LED drivers, LVD, POR, and PWM, along with 23 programmable I/Os.

Microcontrollers Feature Summary

• Integrates 4KB non-volatile FLASH memory for program storage.
• Includes built-in low voltage detection and power-on reset circuits.
• Supports pulse width modulation for signal control applications.

Microcontrollers Applications

• General-purpose embedded control systems
• Industrial monitoring devices
• Consumer electronics logic controllers

Microcontrollers Procurement Notes

Verify the specific manufacturer designation, as this part may be listed under NXP USA Inc. following corporate acquisitions. Confirm the exact suffix 'ECDWER' matches the required package and temperature grade. Check current availability status as older HC08 series components may have limited stock or obsolescence notices.

Microcontrollers Selection Notes

Select this component when an 8-bit architecture with integrated FLASH and minimal peripheral requirements is needed. Ensure the design accommodates the 2.7V to 3.3V operating voltage. Verify that the 20-pin SOIC footprint fits the PCB layout constraints compared to alternative pin counts in the same family.

Microcontrollers Part Context

This MCU belongs to the MC908/JL3E family, designed for cost-sensitive applications requiring reliable 8-bit processing. It utilizes SuperFlash technology for endurance. The JL3E variant specifically targets compact designs with moderate I/O needs, balancing performance and power consumption for basic automation tasks.

Microcontrollers Replacement Considerations

Check for direct cross-references within the MC908KL3E or MC908KK3E families if pin compatibility allows. Verify if the MC68HC908JL3E datasheet specifies equivalent electrical characteristics for any legacy replacements.
