MC9S08GT32ACFDER

$6.15

Description：IC MCU 8BIT 32KB FLASH 48QFN
Series：S08
Mfr：NXP USA Inc.
Package：Tape & Reel (TR)
Core Processor：S08

SKU:9385fc74a265 Category: Microcontrollers Brand: NXP USA Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MC9S08GT32ACFDER is listed in the Microcontrollers range at ChipApex. The manufacturer field lists NXP USA Inc.. Its product description is IC MCU 8BIT 32KB FLASH 48QFN. Review the specifications below when checking this part for your BOM.

Microcontrollers specifications for MC9S08GT32ACFDER

Description：IC MCU 8BIT 32KB FLASH 48QFN
Series：S08
Mfr：NXP USA Inc.
Package：Tape & Reel (TR)
Core Processor：S08
Core Size：8-Bit
Speed：40MHz
Connectivity：I2C, SCI, SPI
Peripherals：LVD, POR, PWM, WDT
Number of I/O：39
Program Memory Size：32KB (32K x 8)
Program Memory Type：FLASH
EEPROM Size：-
RAM Size：2K x 8
Voltage - Supply (Vcc/Vdd)：1.8V ~ 3.6V
Data Converters：A/D 8x10b
Oscillator Type：Internal
Operating Temperature：-40°C ~ 85°C (TA)
Mounting Type：Surface Mount
Supplier Device Package：48-QFN-EP (7x7)
Package / Case：48-VFQFN Exposed Pad
Grade：-
Qualification：-

Microcontrollers datasheet and documents for MC9S08GT32ACFDER

MC9S08GT32ACFDER

Microcontrollers Overview

The MC9S08GT32ACFDER is an 8-bit microcontroller from the S08GT series, manufactured by NXP USA Inc. It features a 40 MHz maximum clock frequency and utilizes the S08 core architecture. The device includes 32 kB of Flash program memory and 2 kB of data RAM. It operates within a supply voltage range of 1.8 V to 3.6 V and supports an industrial temperature range from -40°C to +85°C. The component is housed in a 48-pin QFN package with exposed pad (QFN-48EP). Peripheral interfaces include SCI, SPI, and I2C, alongside an 8-channel 10-bit ADC.

Microcontrollers Feature Summary

Integrates SuperFlash technology for non-volatile memory operations.
Supports multiple low-power modes including Stop1, Stop2, and Stop3.
Features an internal clock generator with FLL capabilities.

Microcontrollers Applications

Industrial control systems
Consumer electronics
Automotive applications

Microcontrollers Procurement Notes

Verify the specific ordering suffix 'DER' against official documentation to confirm tape-and-reel packaging specifications. Ensure compatibility with the 48-QFN-EP mechanical outline, noting potential migration details regarding wire bonding materials if sourcing legacy stock. Confirm RoHS compliance status directly with the manufacturer or authorized distributors.

Microcontrollers Selection Notes

Select this component when a balance of moderate code capacity and peripheral connectivity is required for cost-sensitive embedded designs. The 32 kB Flash size accommodates complex logic while maintaining a compact footprint. Verify that the 1.8 V to 3.6 V operating voltage aligns with the target system power rails before finalizing the design.

Microcontrollers Part Context

This part belongs to the MC9S08GBxxA/GTxxA family, which shares architectural similarities but differs in memory sizes and pin counts. The GT series specifically targets applications requiring efficient processing with integrated analog peripherals. Documentation references indicate updates to package outlines due to manufacturing process changes.
