MCB10-800-RC

Chip Ferrite Bead Overview

The MCB10-800-RC is a mid-current chip bead manufactured by Allied Components International. It features an impedance of 75 ohms at 100 MHz with a tolerance of +/- 25%. The component operates within a temperature range of -55°C to +125°C. Its physical dimensions are 2.00mm in length and 1.25mm in width, corresponding to the 0805 metric package size.

Chip Ferrite Bead Feature Summary

• Provides electromagnetic interference suppression through high impedance characteristics at 100 MHz
• Designed for surface mount assembly on printed circuit boards
• Capable of operating reliably across a wide industrial temperature spectrum

Chip Ferrite Bead Applications

• Signal line filtering in electronic circuits
• Noise suppression in data transmission interfaces
• Electromagnetic compatibility enhancement in consumer electronics

Chip Ferrite Bead Procurement Notes

Verify the specific impedance value and tolerance against the official datasheet before procurement. Confirm that the 0805 footprint matches the target PCB layout. Ensure the supplier provides documentation confirming compliance with RoHS standards as indicated in product descriptions.

Chip Ferrite Bead Selection Notes

Select this component when a 75-ohm impedance at 100 MHz is required for noise attenuation. Consider the 0805 package size for space-constrained designs. Evaluate the -55°C to +125°C operating range against environmental conditions. Compare current handling capabilities if power dissipation is a concern.

Chip Ferrite Bead Part Context

This part belongs to the MCB10 series of mid-current chip beads from Allied Components International. These components are designed for general-purpose noise suppression in compact electronic assemblies. The series offers various impedance values to suit different frequency requirements while maintaining standard surface mount dimensions.

Chip Ferrite Bead Replacement Considerations

Cross-reference other MCB10 series parts for alternative impedance values. Verify pinout and dimensional compatibility with existing board layouts. Check manufacturer specifications for equivalent performance in similar applications.
