Product Detailed Parameters
- Description：MOD THYRISTOR/DIODE 1600V Y4-M6
- Series：-
- Mfr：IXYS
- Package：Box
- Structure：Series Connection - SCR/Diode
- Number of SCRs, Diodes：1 SCR, 1 Diode
- Voltage - Off State：1.6 kV
- Current - On State (It (AV)) (Max)：190 A
- Current - On State (It (RMS)) (Max)：300 A
- Current - Non Rep. Surge 50, 60Hz (Itsm)：6000A, 6400A
- Operating Temperature：-40°C ~ 125°C (TJ)
- Mounting Type：Chassis Mount
- Package / Case：Y4-M6
- Voltage - Gate Trigger (Vgt) (Max)：2.5 V
- Current - Gate Trigger (Igt) (Max)：150 mA
- Current - Hold (Ih) (Max)：200 mA
- Grade：-
- Qualification：-
Download product information
Overview
The IXYS MCD162-16IO1 is a single thyristor module designed for panel mounting. It features a rated RMS on-state current of 190A and a repetitive peak reverse voltage of 1600V. The device supports a surge current rating of 6.4kA with a maximum gate trigger current of 150mA. Key electrical parameters include a peak on-state voltage of 1.25V, a maximum holding current of 200mA, and a maximum gate trigger voltage of 2.5V. The component operates at a maximum temperature of 125°C and has a repetitive peak off-state current of 10mA. Physical dimensions are 94mm in length and 30mm in height, utilizing a 5-pin configuration.
Feature Summary
- Panel mount installation design
- High surge current capability
- Robust thermal performance
Applications
- Industrial motor control systems
- Power rectification circuits
- Industrial heating applications
Procurement Notes
Verify the manufacturer part number against official IXYS documentation to ensure authenticity. Confirm that the specific revision matches the required technical specifications. Check for any physical damage or contamination on the terminals before integration into power electronics assemblies.
Selection Notes
Select this module based on its 190A RMS current capacity and 1600V blocking voltage requirements. Ensure the application environment supports the specified 125°C maximum operating temperature. Verify that the gate drive circuit can supply the necessary 150mA trigger current reliably.
Part Context
This component belongs to the IXYS thyristor module family, which provides high-power semiconductor solutions for industrial applications. The series is known for reliability in demanding power conversion environments. IXYS specializes in efficiency-focused power semiconductors including MOSFETs and IGBTs alongside these discrete modules.
Replacement Considerations
Consult official IXYS documentation for direct cross-references. Modules with similar current ratings and voltage classes may serve as alternatives if pin compatibility and thermal characteristics align. Verify all electrical parameters match before substitution.
