MCI1608HQ2N2SHBPR5

$0.01

Description：MCI-HQ,1608,2.2NH,0.3,DCR0.10,30
Series：MCI HQ
Mfr：INPAQ Technology Co., Ltd
Package：Tape & Reel (TR)

SKU:77cef610db5f Category: Fixed Inductors Brand: INPAQ Technology Co., Ltd

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MCI1608HQ2N2SHBPR5 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists INPAQ Technology Co., Ltd. Its product description is MCI-HQ,1608,2.2NH,0.3,DCR0.10,30. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for MCI1608HQ2N2SHBPR5

Description：MCI-HQ,1608,2.2NH,0.3,DCR0.10,30
Series：MCI HQ
Mfr：INPAQ Technology Co., Ltd
Package：Tape & Reel (TR)
Type：Multilayer
Material - Core：Ceramic
Inductance：2.2 nH
Tolerance：±0.3nH
Current Rating (Amps)：1:00 AM
Current - Saturation (Isat)：-
Shielding：Unshielded
DC Resistance (DCR)：100mOhm Max
Q @ Freq：8 @ 100MHz
Frequency - Self Resonant：8GHz
Ratings：-
Operating Temperature：-55°C ~ 125°C
Inductance Frequency - Test：100 MHz
Mounting Type：Surface Mount
Package / Case：0603 (1608 Metric)
Supplier Device Package：603
Size / Dimension：0.063" L x 0.031" W (1.60mm x 0.80mm)
Height - Seated (Max)：0.037" (0.95mm)
Features：-

Fixed Inductors datasheet and documents for MCI1608HQ2N2SHBPR5

MCI1608HQ2N2SHBPR5

Fixed Inductors Overview

The MCI1608HQ2N2SHBPR5 is a 2.2 nH unshielded multilayer inductor manufactured by INPAQ Technology Co., Ltd. Housed in a 0603 (1608 Metric) package, it supports a maximum current of 1 A with a maximum DC resistance of 100 mOhm. The component utilizes particular ceramic materials and coil structures to enable high-frequency applications up to 10 GHz.

Fixed Inductors Feature Summary

Unshielded multilayer construction designed for high-frequency RF applications
Utilizes specific ceramic materials and coil structures for performance up to 10 GHz
Small size and low profile suitable for compact circuit designs

Fixed Inductors Applications

High-frequency RF circuits
Computing electronics
Communication systems
Automotive electronics

Fixed Inductors Procurement Notes

Verify the complete part number including the suffix against official INPAQ documentation to ensure correct packaging and specifications. Confirm that the 0603 footprint matches your PCB design requirements. Check for RoHS compliance certificates if required by your manufacturing standards. Ensure the 1 A current rating meets your circuit's operational needs.

Fixed Inductors Selection Notes

Select this component when an unshielded inductor is required for frequencies up to 10 GHz. The 0603 package offers a balance between size and electrical performance. Consider the 100 mOhm DC resistance impact on power loss. Verify that the lack of shielding does not cause interference in dense layouts.

Fixed Inductors Part Context

This part belongs to INPAQ's multilayer ceramic RF inductor series. These components are engineered for computing, communication, consumer, and automotive markets. The series emphasizes small size, low profile, and high reliability through monolithic construction techniques typical of INPAQ's electronic component portfolio.

Fixed Inductors Replacement Considerations

Cross-reference with other 2.2 nH 0603 unshielded multilayer inductors from INPAQ or other manufacturers. Ensure equivalent S-parameter characteristics for RF matching. Verify identical package dimensions and terminal configurations for direct replacement.
