MCM-9070M-102

Common Mode Chokes Overview

The Pulse Electronics MCM-9070M-102 is a surface-mount common mode choke designed for power line noise countermeasures. It belongs to the BPPM series and utilizes a ferrite core with wirewound construction. The component features a shielded design to minimize electromagnetic interference. It is manufactured by Chilisin Power under license from Pulse Electronics. The device supports PCB mounting and operates within standard industrial temperature ranges. It is supplied in reel packaging for automated assembly processes.

Common Mode Chokes Feature Summary

• Provides effective common mode noise suppression for power lines
• Features a shielded structure to contain magnetic fields
• Utilizes a ferrite core material for high permeability
• Designed for surface mount technology integration

Common Mode Chokes Applications

• Power line noise filtering in electronic circuits
• Electromagnetic interference suppression in consumer electronics
• Signal integrity protection in data transmission lines

Common Mode Chokes Procurement Notes

Verify the manufacturer designation as Chilisin Power or Mag Layers depending on the specific supply chain source, as both are associated with this part number. Confirm RoHS compliance status through the official datasheet before procurement. Ensure the ordering suffix matches the required packaging format. Cross-reference the Mouser number 673-BPPM090748102X00 for accurate identification during sourcing.

Common Mode Chokes Selection Notes

Select this component when shielding and compact form factor are required for common mode noise reduction. Consider the physical dimensions of 9.0mm x 7.0mm x 4.8mm for board space constraints. Evaluate the impedance characteristics against the target frequency range of interference. Ensure compatibility with the intended current rating and saturation limits for the specific application circuit.

Common Mode Chokes Part Context

This component is part of the BPPM series of common mode chokes produced by Chilisin Power. It serves as an alternative to other surface-mount filters in the market. The part is categorized under inductors, chokes, and coils. It is widely used in applications requiring robust noise filtering solutions.

Common Mode Chokes Replacement Considerations

The part number alias SCDS6D38T-150M-S-N may be referenced in some catalogs. Verify electrical parameters such as impedance and current rating before substituting with generic equivalents. Check package dimensions to ensure mechanical fit.
