Product Detailed Parameters
- Description：MOD THYRISTOR TRI 22KV E2
- Series：-
- Mfr：IXYS
- Package：Box
- Structure：Bridge, 3-Phase - SCRs/Diodes - IGBT with Diode
- Number of SCRs, Diodes：3 SCRs, 3 Diodes
- Voltage - Off State：2.2 kV
- Current - On State (It (AV)) (Max)：-
- Current - On State (It (RMS)) (Max)：-
- Current - Non Rep. Surge 50, 60Hz (Itsm)：500A, 540A
- Operating Temperature：-40°C ~ 150°C (TJ)
- Mounting Type：Chassis Mount
- Package / Case：E2
- Voltage - Gate Trigger (Vgt) (Max)：1.4 V
- Current - Gate Trigger (Igt) (Max)：70 mA
- Current - Hold (Ih) (Max)：100 mA
- Grade：-
- Qualification：-
Download product information
Overview
The MCNA120UI2200TED is a high-voltage thyristor module manufactured by IXYS, classified as a bridge rectifier within the MCNA120UI2200 series. It utilizes silicon technology and features a TO-240AA package with screw mount installation. The component supports an operating temperature range from -40°C to +125°C. Key electrical parameters include a rated repetitive off-state voltage of 2.2 kV, an on-state RMS current of 120 A, and a non-repetitive on-state peak current of 500 A. The device exhibits a maximum on-state voltage of 1.27 V, a holding current maximum of 100 mA, a gate trigger voltage of 1.4 V, and a gate trigger current of 70 mA.
Feature Summary
- High voltage thyristor bridge configuration for robust power conversion
- Silicon-based construction ensuring reliable operation in demanding environments
- Standardized TO-240AA mechanical footprint for simplified integration
Applications
- Industrial motor drives requiring high voltage isolation
- Power supply systems utilizing phase-controlled rectification
- HVDC transmission equipment components
Procurement Notes
Verify the specific suffix TED against official datasheets to confirm exact pinout and thermal characteristics. Ensure compatibility with existing cooling solutions due to the TO-240AA form factor. Confirm RoHS compliance status through manufacturer documentation prior to final assembly approval.
Selection Notes
Select this module when a 2.2 kV blocking capability and 120 A continuous conduction are required in a bridge topology. Consider the TO-240AA package constraints for PCB or chassis mounting. Evaluate thermal management requirements based on the specified on-state voltage and RMS current ratings.
Part Context
This component belongs to the MCNA120UI2200 series of high-power thyristor modules. It represents a specialized solution for applications needing high voltage handling and significant current capacity within a standardized industrial package format provided by IXYS.
Replacement Considerations
Consult official cross-reference lists for verified substitutes. Generic replacements may differ in thermal resistance or gate triggering characteristics.
