MCP1703A-1802E/DB

$0.71

Description：IC REG LIN 1.8V 200MA SOT-223-3
Series：-
Mfr：Microchip Technology
Package：Tube

SKU:a16c82945134 Category: Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Brand: Microchip Technology

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MCP1703A-1802E/DB is listed in the Voltage Regulators - Linear, Low Drop Out (LDO) Regulators range at ChipApex. The manufacturer field lists Microchip Technology. Its product description is IC REG LIN 1.8V 200MA SOT-223-3. Review the specifications below when checking this part for your BOM.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators specifications for MCP1703A-1802E/DB

Description：IC REG LIN 1.8V 200MA SOT-223-3
Series：-
Mfr：Microchip Technology
Package：Tube
Output Configuration：Positive
Output Type：Fixed
Number of Regulators：1
Voltage - Input (Max)：16V
Voltage - Output (Min/Fixed)：1.8V
Voltage - Output (Max)：-
Voltage Dropout (Max)：-
Current - Output：200mA
Current - Quiescent (Iq)：5 µA
Current - Supply (Max)：-
PSRR：35dB (100Hz)
Control Features：-
Protection Features：Over Current, Over Temperature, Short Circuit
Operating Temperature：-40°C ~ 125°C
Mounting Type：Surface Mount
Package / Case：TO-261-4, TO-261AA
Supplier Device Package：SOT-223-3
Grade：-
Qualification：-

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators datasheet and documents for MCP1703A-1802E/DB

MCP1703A-1802E/DB

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Overview

The MCP1703A-1802E/DB is a fixed-output low dropout linear regulator manufactured by Microchip Technology. It provides a regulated 1.8 V output with a maximum continuous current of 200 mA, as the output voltage is below the 2.5 V threshold for 250 mA capability. The device operates within an input voltage range of 2.7 V to 16.0 V and features a typical quiescent current of 2.0 µA. It utilizes a SOT-223-3 surface-mount package and maintains stability with ceramic output capacitance between 1.0 µF and 22 µF.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Feature Summary

Low quiescent current consumption suitable for battery-powered applications
High input voltage operating range up to 16.0 V
Stable operation with small ceramic output capacitors
Integrated short-circuit and overtemperature protection

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Applications

Battery-powered devices
Microcontroller power supplies
Portable consumer electronics
Smart battery packs

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Procurement Notes

Verify the specific suffix E/DB corresponds to the SOT-223-3 package configuration required for your PCB layout. Confirm that the 1.8 V fixed output aligns with system voltage requirements, noting the reduced 200 mA current limit for outputs under 2.5 V. Ensure compliance with RoHS directives if applicable to your manufacturing standards.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Selection Notes

Select this component when a stable 1.8 V rail is needed from inputs ranging up to 16 V. The SOT-223-3 package offers better thermal performance than smaller alternatives. Consider the 200 mA current limitation for loads exceeding this threshold. Verify that the application environment stays within the -40°C to +125°C junction temperature range.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Part Context

This part belongs to the MCP1703A family of micropower LDO regulators. It serves as an improved version of the original MCP1703, offering faster startup times and reduced ground current during dropout conditions. The family supports various fixed output voltages and multiple package options including SOT-23A and DFN.
