MD105S-18I5 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists MicroPower Direct. Its product description is DC/DC,1W,5VIN,18VOUT,5.2 KVISO. Review the specifications below when checking this part for your BOM.
DC DC Converters specifications for MD105S-18I5
- Description：DC/DC,1W,5VIN,18VOUT,5.2 KVISO
- Series：MD100 (1W)
- Mfr：MicroPower Direct
- Package：Tube
- Type：Isolated Module
- Number of Outputs：1
- Voltage - Input (Min)：4.5V
- Voltage - Input (Max)：5.5V
- Voltage - Output 1：18V
- Voltage - Output 2：-
- Voltage - Output 3：-
- Voltage - Output 4：-
- Current - Output (Max)：56mA
- Power (Watts)：1 W
- Voltage - Isolation：5.2 kV
- Applications：ITE (Commercial)
- Features：-
- Operating Temperature：-40°C ~ 85°C (With Derating)
- Efficiency：83%
- Mounting Type：Through Hole
- Package / Case：7-SIP Module, 4 Leads
- Size / Dimension：0.77" L x 0.24" W x 0.39" H (19.5mm x 6.0mm x 10.0mm)
- Supplier Device Package：-
- Control Features：-
- Approval Agency：CE, cURus, UKCA
- Standard Number：62368-1
- Grade：-
- Qualification：-
DC DC Converters datasheet and documents for MD105S-18I5
