MDF7-10P-2.54DSA(01)

Headers, Male Pins Overview

The MDF7-10P-2.54DSA(01) is a board-to-board connector header manufactured by Hirose Electric Co Ltd, belonging to the MDF7 series. It features 10 positions with a 0.100" (2.54mm) pitch and utilizes male pin contacts. The component is designed for through-hole mounting with solder termination. It has a single row configuration and square contact shapes. The housing is made of black polybutylene terephthalate (PBT) with UL94 V-0 flammability rating. Contact plating is gold on the mating interface and tin on the column. Rated current is 3A at 250VAC, operating within -35°C to 85°C.

Headers, Male Pins Feature Summary

• Push-pull locking mechanism ensures secure connection stability
• Bottom entry design facilitates precise alignment during assembly
• Gold-plated mating contacts provide reliable conductivity

Headers, Male Pins Applications

• Board-to-board interconnections in electronic assemblies
• Mezzanine connector applications requiring vertical stacking
• High-density circuit board connections

Headers, Male Pins Procurement Notes

Verify part status as obsolete before procurement planning. Confirm availability of replacement alternatives such as MDF7-10P-2.54DSA(96). Check RoHS compliance and MSL level 1 requirements. Ensure compatibility with existing PCB footprint designs. Validate supplier documentation for manufacturing changes.

Headers, Male Pins Selection Notes

Select this component for applications requiring 10-position through-hole headers with push-pull retention. Consider the 2.54mm pitch constraint and vertical orientation. Evaluate thermal performance within the specified temperature range. Assess mechanical stability needs for bottom-entry configurations. Verify insulation material compatibility with soldering processes.

Headers, Male Pins Part Context

This connector belongs to the MDF7 series, which offers various position counts and packaging options. The series provides standardized dimensions for consistent assembly across different product lines. Alternative suffixes indicate different packaging methods while maintaining electrical characteristics.

Headers, Male Pins Replacement Considerations

MDF7-10P-2.54DSA(96) serves as a direct substitute with identical electrical specifications but different packaging.
