MDF7-14P-2.54DS(56)

Headers, Male Pins Overview

The Hirose Electric Co Ltd MDF7-14P-2.54DS(56) is a board-to-board connector from the MDF7 series, designed for right-angle through-hole mounting. It features 14 positions with a 0.100-inch (2.54mm) pitch and utilizes male pin contacts. The component is rated for 3A current and 250V voltage, operating within a temperature range of -35°C to 85°C. Constructed with PBT insulation and brass contacts, it employs a push-pull fastening mechanism and meets UL94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Right-angle orientation facilitates space-efficient PCB layout
• Push-pull fastening mechanism ensures secure connection retention
• Through-hole termination provides robust mechanical stability

Headers, Male Pins Applications

• Board-to-board interconnections in compact electronic assemblies
• Mezzanine connectivity requiring right-angle routing
• Industrial control modules with limited vertical clearance

Headers, Male Pins Procurement Notes

Verify component obsolescence status prior to procurement planning. Confirm availability of direct substitutes or alternative series components. Validate that the right-angle configuration and specific pin count meet design requirements. Ensure compatibility with mating connectors regarding pitch and contact type. Review manufacturer notifications for any material or sourcing changes affecting long-term supply.

Headers, Male Pins Selection Notes

Select this component only if right-angle mounting is required for the specific application. Verify that the 14-position count aligns with circuit interface needs. Confirm that through-hole technology is compatible with the manufacturing process. Assess whether the push-pull mechanism suits the assembly environment. Evaluate thermal and electrical ratings against operational demands.

Headers, Male Pins Part Context

This part belongs to the MDF7 series of board-to-board connectors manufactured by Hirose Electric Co Ltd. The series is characterized by high-density interconnect solutions utilizing push-pull locking systems. These connectors are engineered for reliable performance in demanding electronic environments, supporting various pin counts and configurations.

Headers, Male Pins Replacement Considerations

Direct substitute: MDF7-14P-2.54DSA(56). Verify physical compatibility and mating interface alignment before substitution.
