MDF7P-16DP-2.54DSA(55)

Headers, Male Pins Overview

The MDF7P-16DP-2.54DSA(55) is a board-to-board and mezzanine connector header manufactured by Hirose Electric Co Ltd. It features a 16-position, double-row pin header configuration with a 2.54 mm (0.1 in) pitch. The component utilizes straight through-hole termination and operates within a temperature range of -30°C to +85°C. Electrical ratings include a current capacity of 3 A and a voltage rating of 250 VAC. Contacts are made of brass with tin plating, while the housing is constructed from Polybutylene Terephthalate (PBT).

Headers, Male Pins Feature Summary

• Double-row pin header design for high-density interconnections.
• Straight through-hole mounting for secure PCB attachment.
• Bottom entry contact style facilitates specific mating orientations.

Headers, Male Pins Applications

• Board-to-board connections in compact electronic assemblies.
• Mezzanine connector interfaces requiring vertical stacking.
• Industrial control modules needing reliable signal routing.

Headers, Male Pins Procurement Notes

Verify component availability status as this part may be discontinued or subject to supply constraints. Confirm that the specific ordering suffix matches the required double-row configuration and housing material specifications. Ensure compatibility with mating receptacles from the same series before procurement.

Headers, Male Pins Selection Notes

Select this component when a 16-position double-row header is required for board-to-board applications. Verify that the 2.54 mm pitch aligns with the target PCB footprint and mating connector standards. Consider the operating temperature range and electrical ratings to ensure suitability for the intended circuit environment.

Headers, Male Pins Part Context

This component belongs to the MDF7 series of board-to-board connectors. The series offers various position counts and row configurations to support diverse connectivity needs. The MDF7P variant specifically denotes the pin header counterpart designed to mate with MDF7 receptacles.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Evaluate alternative Hirose series components only if they match the exact pitch, row count, and mechanical dimensions.
