MEA1608PH150TA0G

Overview

The MEA1608PH150TA0G is a surface-mount EMI filter circuit from TDK's MEA-PH series, housed in a 0603 (1608 metric) package. It operates with a voltage rating of 6.3 V and a current rating of 100 mA. The component features a PI-filter topology with a capacitance of 15 pF and a cutoff frequency of 480 MHz. It functions within a temperature range of -40°C to +85°C.

Feature Summary

• Provides effective electromagnetic interference suppression through a PI-filter network structure
• Designed for high-frequency signal line filtering applications
• Utilizes a compact surface-mount form factor suitable for space-constrained layouts

Applications

• High-speed data interface protection
• Signal line noise suppression in portable electronics
• EMI mitigation in communication modules

Procurement Notes

Verify the specific suffix TA0G against the manufacturer's latest documentation to confirm packaging details and RoHS compliance status. Ensure the selected variant matches the required termination type and reel specifications for automated assembly processes. Cross-reference the full part number with official distributor catalogs to avoid ordering errors due to similar family members.

Selection Notes

Select this component when a PI-filter configuration is required for signals operating up to 6.3 V. The 100 mA current rating and 15 pF capacitance define its impedance characteristics. Consider the 0603 footprint constraints and the 480 MHz cutoff frequency relative to the target signal bandwidth. Verify thermal performance requirements against the specified operating temperature range.

Part Context

This component belongs to the TDK MEA-PH series of EMI filters. These devices are engineered for suppressing high-frequency noise in sensitive electronic circuits. The series offers various configurations tailored for different signal integrity needs while maintaining a small physical profile compatible with modern surface-mount technology standards.

Replacement Considerations

Consult TDK's official substitution guide for verified alternatives within the MEA series. Direct replacements must match the 0603 package, 6.3 V rating, and PI-filter topology. Generic equivalents may not replicate the specific 480 MHz cutoff performance.
