MEA2010LD220T002

Overview

The MEA2010LD220T002 is a third-order LC low-pass EMI/RFI filter manufactured by TDK Corporation. It features a surface-mount design with three terminals and utilizes an LC network topology for signal filtering. The component is RoHS3 compliant and operates within a voltage range up to 6.3V, with a capacitance value of 22pF. It is packaged in tape and reel format for automated assembly processes.

Feature Summary

• Third-order LC low-pass filtering architecture
• Three-terminal surface-mount construction
• RoHS3 compliance without halogen or lead

Applications

• General EMI suppression in electronic circuits
• Signal line noise reduction in consumer electronics
• RFI mitigation in automotive subsystems

Procurement Notes

Verify the specific datasheet version and RoHS3 certification status directly with TDK Corporation or authorized distributors before procurement. Confirm that the 6.3V rating and 22pF capacitance align with your circuit requirements. Ensure compatibility with standard SMD reflow soldering profiles as specified in the official documentation.

Selection Notes

Select this component when a compact, third-order LC filter is required for low-voltage applications. The 2010 package size offers a balance between footprint constraints and performance. Consider the 6.3V maximum operating voltage limit during selection to ensure reliability under peak signal conditions.

Part Context

This part belongs to the MEA series of EMI filters from TDK. The series provides various capacitance values and configurations for different filtering needs. The MEA2010LD220T002 specifically addresses high-frequency noise suppression in space-constrained designs requiring robust attenuation characteristics.

Replacement Considerations

Consult TDK's official substitution guide for verified alternatives. Cross-reference pinout and electrical parameters carefully if considering non-TDK equivalents to ensure functional compatibility.
