MEC1-105-02-F-D-NP-A-K-TR

Edgeboard Connectors Overview

The MEC1-105-02-F-D-NP-A-K-TR is a standard card edge connector socket from the Samtec MEC1 series. It features a 1.00 mm pitch and provides 10 positions arranged in a dual-row configuration. The component utilizes beryllium copper contacts with gold plating to ensure reliable signal transmission. Designed for surface mount installation, it operates within a temperature range of -55°C to +125°C. The housing is constructed from liquid crystal polymer (LCP), offering high thermal stability. The unit supports a current rating of 2.2 A and a voltage rating of 300 V.

Edgeboard Connectors Feature Summary

• Dual-edge board connection capability via a 10-position dual-row interface
• Gold-plated beryllium copper contacts for enhanced conductivity and durability
• Liquid crystal polymer housing providing structural integrity at elevated temperatures

Edgeboard Connectors Applications

• High-density electronic interconnects requiring precise alignment
• Industrial control systems operating in extreme temperature environments
• Telecommunications equipment utilizing standard card edge modules

Edgeboard Connectors Procurement Notes

Verify the specific suffix 'K-TR' against official documentation to confirm reel packaging specifications and quantity per reel. Ensure the ordering code matches the required contact finish and termination style. Cross-reference the manufacturer datasheet for any recent design changes or compliance updates before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this component when a 1.00 mm pitch dual-row socket is required for surface mount applications. Confirm that the mating card edge thickness aligns with the connector's tolerance. Evaluate the mechanical constraints of the PCB layout to accommodate the straight mounting profile and ensure adequate clearance for the LCP housing during assembly.

Edgeboard Connectors Part Context

This part belongs to the MEC1 series of mini edge card sockets designed by Samtec. The series offers various position counts and termination options to support diverse board-to-board connectivity needs. The MEC1 line is characterized by its compact form factor and robust electrical performance suitable for modern electronic assemblies.

Edgeboard Connectors Replacement Considerations

Direct substitutes include other MEC1 series variants with matching 10-position dual-row configurations and 1.00 mm pitch. Verify compatibility regarding contact material, housing color, and termination type before substitution.

Edgeboard Connectors FAQ

What is the contact material used in this connector?

The contacts are made from beryllium copper with a gold plating finish.

Does this connector support surface mount installation?

Yes, the MEC1-105-02-F-D-NP-A-K-TR is designed for surface mount termination.
