MGV0603R10M-10

$0.27

Description：FIXED IND 100NH 32.5A 1.7MOHM SM
Series：MGV
Mfr：Laird-Signal Integrity Products
Package：Tape & Reel (TR)

SKU:67c061c329aa Category: Fixed Inductors Brand: Laird-Signal Integrity Products

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MGV0603R10M-10 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Laird-Signal Integrity Products. Its product description is FIXED IND 100NH 32.5A 1.7MOHM SM. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for MGV0603R10M-10

Description：FIXED IND 100NH 32.5A 1.7MOHM SM
Series：MGV
Mfr：Laird-Signal Integrity Products
Package：Tape & Reel (TR)
Type：Molded
Material - Core：-
Inductance：100 nH
Tolerance：±20%
Current Rating (Amps)：32.5 A
Current - Saturation (Isat)：60A
Shielding：Shielded
DC Resistance (DCR)：1.7mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.287" L x 0.264" W (7.30mm x 6.70mm)
Height - Seated (Max)：0.130" (3.30mm)
Features：-

Fixed Inductors datasheet and documents for MGV0603R10M-10

MGV0603R10M-10

Fixed Inductors Overview

MGV0603R10M-10 is a shielded molded power inductor from Laird-Signal Integrity Products. It features an inductance of 100 nH with ±20% tolerance and a maximum DC resistance of 1.7 mOhm. The component supports a rated current of 32.5 A and a saturation current of 43 A. Designed for surface mount installation, it operates within a temperature range of -40°C to 125°C. The physical dimensions are non-standard, measuring approximately 7.3 mm in length, 6.7 mm in width, and 3.3 mm in height.

Fixed Inductors Feature Summary

Shielded molded construction minimizes electromagnetic interference
High current handling capability for power applications
Low DC resistance for efficient power delivery

Fixed Inductors Applications

Power supply circuits
DC-DC converter modules
Point-of-load regulation systems

Fixed Inductors Procurement Notes

Verify the specific manufacturer designation, as sources list both Laird and Qnity. Confirm the exact package dimensions against the official datasheet due to the non-standard classification. Ensure the selected variant matches the required current ratings for the target application design.

Fixed Inductors Selection Notes

Select this component for designs requiring high current density in a compact footprint. The shielded structure reduces magnetic coupling issues in dense layouts. Verify thermal performance under load conditions to ensure operation remains within the specified temperature limits during continuous duty cycles.

Fixed Inductors Part Context

This part belongs to the MGV series of fixed power inductors. It is designed for surface mount technology (SMT) applications. The series offers various inductance values tailored for different power management requirements in electronic devices.
