MIC94061YC6-TR

Overview

The MIC94061YC6-TR is a high-side power switch IC from Microchip Technology, designed for power distribution applications. It features a single output capable of delivering up to 2A of current with a maximum on-resistance of 110 mΩ. The device operates within a supply voltage range of 1.7V to 5.5V and includes integrated level-shift and load-discharge functionalities. Key timing parameters include a maximum turn-on time of 1.2 ms and a maximum idle time of 200 ns. It is housed in a compact SC-70-6 surface-mount package and supports an operating temperature range from -40°C to +85°C.

Feature Summary

• Integrates level-shift capability for flexible control interface compatibility
• Includes built-in load-discharge circuitry for safe power-down sequences
• Provides high-side switching with low on-resistance for efficient power delivery

Applications

• Power distribution networks in embedded systems
• Load switching in portable consumer electronics
• Peripheral power management in industrial control units

Procurement Notes

Verify the exact ordering suffix against the official Microchip datasheet to ensure correct packaging and temperature grade. Confirm that the SC-70-6 package variant matches your PCB footprint requirements. Cross-reference the RoHS compliance status with current regulatory standards for your target market. Ensure that the lead-free designation aligns with your assembly process specifications.

Selection Notes

Select this component when a single-channel high-side switch with integrated discharge is required. The 2A current rating suits moderate load applications. The wide input voltage range allows compatibility with various logic levels. Consider the 110 mΩ on-resistance for thermal management in space-constrained designs.

Part Context

This part belongs to Microchip's MIC9406x series of high-side power switches. These devices are engineered for robust power distribution in compact form factors. The series emphasizes ease of use through integrated features like level-shifting and load discharge, reducing external component count.

Replacement Considerations

Consult the Microchip product selector guide for direct pin-to-pin alternatives within the MIC9406x family. Verify that any substitute maintains the same SC-70-6 package and electrical characteristics. Check for updated revisions or superseded part numbers in official documentation.
