MJN2C-DC12

MJN2C-DC12 is listed in the Power Relays, Over 2 Amps range at ChipApex. The manufacturer field lists Omron Automation and Safety. Its product description is RELAY GEN PURPOSE DPDT 10A 12V. Review the specifications below when checking this part for your BOM.

Power Relays, Over 2 Amps specifications for MJN2C-DC12

• Description：RELAY GEN PURPOSE DPDT 10A 12V
• Series：MJN
• Mfr：Omron Automation and Safety
• Package：Bulk
• Mounting Type：Socketable
• Coil Voltage：12VDC
• Contact Form：DPDT (2 Form C)
• Contact Rating (Current)：10:00 AM
• Switching Voltage：600VAC, 28VDC - Max
• Load - Max Switching：6000VA, 280W
• Coil Current：100 mA
• Coil Type：Non Latching
• Features：-
• Termination Style：Plug In, Quick Connect - 0.187" (4.7mm)
• Seal Rating：-
• Coil Insulation：-
• Must Operate Voltage：9 VDC
• Must Release Voltage：-
• Operating Temperature：-45°C ~ 70°C
• Contact Material：Silver Alloy
• Approval Agency：CSA, UR
• Relay Type：General Purpose
• Grade：-
• Qualification：-
• Operate Time：20 ms
• Release Time：10 ms

Power Relays, Over 2 Amps datasheet and documents for MJN2C-DC12
