MK 14 X 3 22 G

Headers, Male Pins Overview

The MK 14 X 3 22 G is a male header connector manufactured by Fischer Elektronik, designed for board-to-board and wire-to-board applications. It features a single row with three contacts and a pitch spacing of 2.54 mm. The component utilizes CuZn-alloy pins that are gold-plated to ensure reliable parallel PCB connection with a pin diameter of 0.5 mm.

Headers, Male Pins Feature Summary

• Gold-plated CuZn alloy pins provide corrosion resistance and stable electrical contact.
• Single-row configuration supports efficient board-to-board or wire-to-board interconnections.
• Precision-engineered 0.5 mm diameter pins facilitate reliable parallel PCB mounting.

Headers, Male Pins Applications

• Parallel PCB connections
• Board-to-board interconnects
• Wire-to-board assemblies

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer's current datasheet to confirm exact pin length and packaging details. Ensure compatibility with mating connectors regarding pitch and row count. Confirm surface mount or through-hole requirements based on the target PCB design before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a single-row, 2.54 mm pitch header is required for low-current signal transmission. The gold plating offers durability in standard environments. Consider the 0.5 mm pin diameter for mechanical stability during soldering and operation. Validate that the nominal current rating aligns with the application's electrical load requirements.

Headers, Male Pins Part Context

Fischer Elektronik specializes in connector systems for printed circuit boards and ribbon cables. The MK series represents their line of male headers and solder plugs. This specific model belongs to a family of precision connectors designed for robust electronic assembly across various industrial and consumer electronics sectors.

Headers, Male Pins Replacement Considerations

Consult official cross-reference lists for verified substitutes. Generic equivalents may differ in pin diameter, plating quality, or mechanical retention strength. Verify that any replacement maintains the 2.54 mm pitch and single-row configuration to ensure physical fitment.

Headers, Male Pins FAQ

What is the contact material for the MK 14 X 3 22 G?

The contacts are made from CuZn alloy and are gold-plated.

Does this connector support multiple rows?

No, the MK 14 X 3 22 G is designed as a single-row connector.
