MK10DX128VMC7

Microcontrollers Overview

The MK10DX128VMC7 is a 32-bit microcontroller based on the ARM Cortex-M4 core with DSP support, operating at a maximum frequency of 72 MHz. It features 128 KB of program flash and 32 KB of SRAM within a 121-pin MAPBGA package. The device supports an operating voltage range of 1.71 V to 3.6 V and functions across an ambient temperature range of -40°C to 105°C.

Microcontrollers Feature Summary

• Integrates a 16-channel DMA controller supporting up to 63 request sources for efficient data transfer.
• Includes hardware touch sensing interface (TSI) for low-power human-machine interaction.
• Provides mixed-signal capabilities with two 16-bit SAR ADCs featuring integrated programmable gain amplifiers.
• Offers comprehensive communication interfaces including CAN, SPI, I2C, UART, and I2S modules.

Microcontrollers Applications

• Industrial control systems requiring robust connectivity and analog signal processing
• Motor control applications utilizing flexible timers and quadrature decoders
• Medical devices needing precise analog measurement and low-power operation

Microcontrollers Procurement Notes

Verify the specific suffix MC7 corresponds to the 121-pin MAPBGA package configuration. Confirm that the ordering part number matches the K10 sub-family requirements for your design. Ensure compatibility with the specified voltage and temperature ranges for your intended application environment before finalizing procurement.

Microcontrollers Selection Notes

Select this component when a high-performance Cortex-M4 core with DSP extensions is required alongside extensive analog peripherals. The inclusion of FlexMemory allows for flexible data storage configurations. Consider the 121-pin MAPBGA package constraints regarding PCB layout and thermal management during the selection process.

Microcontrollers Part Context

This microcontroller belongs to the NXP Kinetis K10 sub-family, designed for mainstream applications. It shares architectural similarities with other K10 variants but is distinguished by its specific memory size and package type. The family emphasizes low power consumption and high integration for cost-effective system designs.

Microcontrollers Replacement Considerations

Compatible substitutes within the K10 series include MK10DX64VMC7 and MK10DX256VMC7, which share the same package and pinout but differ in flash capacity. Verify software compatibility and peripheral availability when transitioning between these variants.
