MK30DX256VLK7

$6.52

Description：IC MCU 32BIT 256KB FLASH 80FQFP
Series：Kinetis K30
Mfr：NXP USA Inc.
Package：Tray
Core Processor：ARM® Cortex®-M4

SKU:a710b8b12ab6 Category: Microcontrollers Brand: NXP USA Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MK30DX256VLK7 is listed in the Microcontrollers range at ChipApex. The manufacturer field lists NXP USA Inc.. Its product description is IC MCU 32BIT 256KB FLASH 80FQFP. Review the specifications below when checking this part for your BOM.

Microcontrollers specifications for MK30DX256VLK7

Description：IC MCU 32BIT 256KB FLASH 80FQFP
Series：Kinetis K30
Mfr：NXP USA Inc.
Package：Tray
Core Processor：ARM® Cortex®-M4
Core Size：32-Bit Single-Core
Speed：72MHz
Connectivity：CANbus, I2C, IrDA, SD, SPI, UART/USART
Peripherals：DMA, I2S, LCD, LVD, POR, PWM, WDT
Number of I/O：56
Program Memory Size：256KB (256K x 8)
Program Memory Type：FLASH
EEPROM Size：2K x 8
RAM Size：64K x 8
Voltage - Supply (Vcc/Vdd)：1.71V ~ 3.6V
Data Converters：A/D 31x16b; D/A 1x12b
Oscillator Type：Internal
Operating Temperature：-40°C ~ 105°C (TA)
Mounting Type：Surface Mount
Supplier Device Package：80-FQFP (12x12)
Package / Case：80-LQFP
Grade：-
Qualification：-

Microcontrollers datasheet and documents for MK30DX256VLK7

MK30DX256VLK7

Microcontrollers Overview

The MK30DX256VLK7 is an ARM Cortex-M4 microcontroller with DSP capabilities from the Kinetis K30 sub-family. It features 256 kB of program flash memory and operates at a maximum CPU frequency of 72 MHz. The device supports a supply voltage range of 1.71 V to 3.6 V and functions within an ambient temperature range of -40°C to 105°C. It is housed in an 80-pin LQFP package (LK) and supplied in tape and reel packaging.

Microcontrollers Feature Summary

Integrates dual 16-bit SAR ADCs with programmable gain amplifiers and a 12-bit DAC for analog signal processing.
Includes multiple communication interfaces such as CAN, SPI, I2C, UART, and I2S modules.
Features a segment LCD controller supporting up to 36 frontplanes and 8 backplanes depending on package size.
Provides hardware security through a CRC module and a unique 128-bit identification number per chip.

Microcontrollers Applications

Industrial control systems requiring robust communication protocols
Human-machine interface designs utilizing segment LCD displays
Battery-powered devices leveraging low-power operating modes

Microcontrollers Procurement Notes

Verify the specific ordering suffix against official NXP documentation to confirm package type, temperature range, and delivery format. Ensure compatibility with existing board layouts regarding pin assignments and power requirements before procurement.

Microcontrollers Selection Notes

Select this component when a balance of processing performance and peripheral integration is required. The 72 MHz speed and extensive analog peripherals make it suitable for applications needing precise signal acquisition and control without excessive power consumption.

Microcontrollers Part Context

This part belongs to the Kinetis K30 sub-family, designed for high-performance embedded applications. It shares architectural similarities with other K30 variants but offers specific memory sizes and package options tailored for diverse design constraints.
