MMPF0100F0ANES

Overview

The MMPF0100F0ANES is a specialized power management integrated circuit (PMIC) designed for NXP i.MX6 processors. It features a 56-QFN-EP package with dimensions of 8x8 mm and supports an input voltage range of 2.8V to 4.5V. The device provides multiple output channels, including buck converters, LDOs, and boost regulators, tailored for heterogeneous processing applications. It operates within a temperature range of -40°C to 105°C and holds AEC-Q100 automotive qualification.

Feature Summary

• Integrated multi-rail power solution optimized for i.MX6 processor families
• Configurable regulator outputs supporting diverse system voltage requirements
• Automotive-grade reliability with AEC-Q100 certification
• Surface-mount packaging with exposed pad for enhanced thermal performance

Applications

• i.MX6SoloX processor-based embedded systems
• Industrial automation control units
• Medical diagnostic equipment
• Home automation hubs

Procurement Notes

Verify the specific suffix 'F0ANES' against official NXP documentation to confirm pre-programmed OTP settings and pin-to-pin compatibility. Ensure the procurement source provides valid RoHS and REACH compliance certificates. Confirm that the supplier handles moisture sensitivity level requirements appropriately during storage and shipping.

Selection Notes

Select this component when designing systems based on the i.MX6 family requiring a single-chip PMIC solution. Consider the 56-pin QFN footprint for board space constraints. Verify that the input voltage range aligns with the system's primary power supply rails. Evaluate the thermal dissipation capabilities of the exposed pad design for high-load scenarios.

Part Context

This part belongs to the MMPF0100 series, a line of configurable PMICs developed by NXP Semiconductors. It serves as a companion power device for the i.MX6 application processor family, simplifying power sequencing and rail management. The series includes variants with different factory programming configurations to suit specific processor needs.

Replacement Considerations

Consult the NXP MMPF0100 datasheet errata for mask revisions 1N47F and 1N18J before substitution. Direct replacements may require verification of OTP configuration matches. Alternative PF series PMICs might offer similar functionality but require schematic review.
