MMT-112-01-L-DH-P

Headers, Male Pins Overview

The Samtec MMT-112-01-L-DH-P is a surface mount, right-angle header connector from the MMT series. It features 12 positions with a 2.00 mm (0.079 inch) pitch and single row configuration. The contacts are male pins made of phosphor bronze with matte tin termination plating. The insulator is constructed from liquid crystal polymer (LCP) rated UL94 V-0. Operating temperature ranges from -55°C to 125°C. This component utilizes a push-pull locking mechanism for secure board-to-board or cable connections.

Headers, Male Pins Feature Summary

• Surface mount right-angle design for compact PCB integration
• Push-pull locking system ensures secure mating retention
• Matte tin plated phosphor bronze contacts for reliable conductivity
• Liquid crystal polymer insulation with UL94 V-0 flammability rating

Headers, Male Pins Applications

• Board-to-board interconnections in industrial electronics
• Cable-to-board assemblies requiring right-angle routing
• Automotive electronic control unit interfaces
• Consumer device internal connectivity modules

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Samtec documentation to confirm exact plating thickness and mechanical tolerances. Ensure compatibility with mating receptacles regarding pin height and locking clip requirements. Confirm RoHS compliance status and moisture sensitivity level prior to assembly planning. Cross-reference part numbers with authorized distributors to avoid counterfeit components.

Headers, Male Pins Selection Notes

Select this model when a right-angle surface mount header with push-pull retention is required. The 2.00 mm pitch suits applications needing moderate density without excessive footprint area. Matte tin plating offers cost-effective conductivity suitable for general purpose environments. Verify that the phosphor bronze contact material meets the current carrying capacity needs of the target circuit design.

Headers, Male Pins Part Context

This component belongs to the MMT series of horizontal surface mount terminal strips by Samtec. The series provides various configurations including vertical and horizontal orientations with different pin counts and plating options. The MMT line is designed for high-reliability connections in space-constrained electronic assemblies, offering robust mechanical stability through its unique locking features.

Headers, Male Pins Replacement Considerations

Direct substitutes within the same series include MMT-112-01-S-DH-P for gold-plated variants or MMT-112-01-L-DH-K-001-P-TR for tape-and-reel packaging. Verify identical pitch, pin count, and mounting orientation before substitution. Contact material and plating differences may affect corrosion resistance and solderability characteristics.
