MP01780

Overview

The MP01780 is a Surface Acoustic Wave (SAW) filter manufactured by Golledge Electronics Ltd. It operates at a center frequency of 480 MHz with a bandwidth of 9 MHz and provides an insertion loss of 14 dB. The component is housed in a compact 10-SMD, No Lead surface-mount package, designed for integration into RF signal processing circuits requiring precise frequency selection.

Feature Summary

• Utilizes Surface Acoustic Wave technology for efficient signal filtering
• Engineered for specific intermediate frequency applications
• Features a leadless surface-mount design for automated assembly

Applications

• RF intermediate frequency filtering
• Wireless communication systems
• Signal processing modules

Procurement Notes

Verify the exact part number against official Golledge Electronics documentation to confirm specifications. Ensure compatibility with your circuit's impedance and frequency requirements before procurement. Check for any specific handling instructions related to the leadless package type during assembly.

Selection Notes

Select this component when a 480 MHz SAW filter with 9 MHz bandwidth is required. Consider the 14 dB insertion loss impact on system gain. The 10-SMD no-lead package dictates specific PCB footprint and soldering profile requirements compared to through-hole alternatives.

Part Context

This component belongs to Golledge Electronics' portfolio of passive RF components, specifically within their SAW filter line. It complements their quartz crystal and oscillator offerings by providing frequency-selective capabilities for downstream signal conditioning stages in electronic devices.
