MP07003

Overview

The MP07003 is a Surface Acoustic Wave (SAW) filter manufactured by Golledge Electronics Ltd, designed for RF applications. It operates at a nominal frequency of 159.0125 MHz with a bandwidth of 6.025 MHz. The device features a maximum insertion loss of 2.8 dB and is housed in a 10-SMD, No Lead package.

Feature Summary

• Utilizes Surface Acoustic Wave technology for signal filtering
• Optimized for pager RF applications
• Compact surface-mount construction

Applications

• Pager RF filtering
• RF signal processing
• Communication device front-ends

Procurement Notes

Verify the component status as obsolete before procurement planning. Confirm the specific package variant matches the 10-SMD, No Lead specification. Ensure the operating frequency aligns with the 159.0125 MHz requirement to maintain system performance integrity.

Selection Notes

Select this component for applications requiring SAW filter characteristics at 159 MHz. Consider the 2.8 dB insertion loss and 6.025 MHz bandwidth when designing the RF chain. Verify compatibility with existing PCB footprints for the 10-SMD package.

Part Context

This part belongs to the GSRF series of SAW filters from Golledge Electronics. It serves as a specialized RF component for niche communication markets, distinct from standard quartz crystals or oscillators offered by the manufacturer.
