MP3366GC-P

$1.00

Description：IC LED DRV RGLTR PWM 18WLCSP
Series：-
Mfr：Monolithic Power Systems Inc.
Package：Tape & Reel (TR)

SKU:bedd701f40c8 Category: LED Drivers IC Brand: Monolithic Power Systems Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC LED DRV RGLTR PWM 18WLCSP
Series：-
Mfr：Monolithic Power Systems Inc.
Package：Tape & Reel (TR)
Type：DC DC Regulator
Topology：Step-Up (Boost)
Internal Switch(s)：Yes
Number of Outputs：6
Voltage - Supply (Min)：3V
Voltage - Supply (Max)：25V
Voltage - Output：45V
Current - Output / Channel：45mA
Frequency：600kHz
Dimming：Analog, PWM
Applications：Backlight
Operating Temperature：-40°C ~ 125°C (TJ)
Mounting Type：Surface Mount
Package / Case：18-UFBGA, WLCSP
Supplier Device Package：18-WLCSP (1.35x2.55)
Grade：-
Qualification：-

Download product information

MP3366GC-P

Overview

The MP3366GC-P is a Monolithic Power Systems LED lighting driver IC featuring a boost topology with six output channels. It operates on a supply voltage range of 3 V to 25 V and delivers a maximum output voltage of 50 V. The device functions at a switching frequency of 600 kHz and supports PWM dimming for white LEDs. Packaged in a WLCSP-18 format, it handles a power dissipation of 1.7 W within an operating temperature range of -40°C to +125°C.

Feature Summary

Six-channel current source design for driving white LED arrays
Integrated PWM dimming capability for brightness control
Boost converter topology optimized for backlighting applications

Applications

White LED backlighting for mid-range displays
General LED lighting systems requiring multi-channel drive
Electronic devices utilizing WLED arrays for illumination

Procurement Notes

Verify the specific suffix against official MPS documentation to confirm package type and tape/reel specifications. Ensure compatibility with system input voltage limits and thermal requirements before integration. Cross-reference the datasheet for exact pinout configurations and electrical characteristics relevant to the final application design.

Selection Notes

Select this component for designs requiring independent control of multiple LED strings within a compact footprint. The WLCSP-18 package offers space efficiency compared to larger alternatives. Consider the 600 kHz switching frequency when designing passive components for electromagnetic interference management and efficiency optimization.

Part Context

This part belongs to the MP3366 series of LED drivers from Monolithic Power Systems. It is functionally similar to the MP3366GC-Z variant, sharing core electrical specifications but potentially differing in packaging or reel configuration. Both are designed for high-efficiency white LED driving in portable and display electronics.

Replacement Considerations

The MP3366GC-Z is a confirmed substitute within the same product family. Verify that any alternative replacement maintains identical channel count, output voltage capabilities, and package dimensions to ensure mechanical and electrical compatibility.
