MP8200DT-LF-P

$0.67

Description：IC VREF SHUNT 1% SOT23-3
Series：-
Mfr：Monolithic Power Systems Inc.
Package：Tape & Reel (TR)

SKU:b0bcd9b29c27 Category: Voltage Reference Brand: Monolithic Power Systems Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC VREF SHUNT 1% SOT23-3
Series：-
Mfr：Monolithic Power Systems Inc.
Package：Tape & Reel (TR)
Output Type：Fixed
Voltage - Output (Min/Fixed)：1V
Voltage - Output (Max)：-
Current - Output：10 mA
Operating Temperature：-40°C ~ 85°C (TA)
Mounting Type：Surface Mount
Package / Case：TO-236-3, SC-59, SOT-23-3
Supplier Device Package：SOT-23-3
Grade：-
Qualification：-

Download product information

MP8200DT-LF-P

Overview

The MP8200DT-LF-P is a precision shunt voltage reference IC from Monolithic Power Systems. It provides a fixed 1.0V output with an initial accuracy of 1%. The device operates within a temperature range of -40°C to +85°C and features a temperature coefficient of 45 PPM/°C. It draws a typical quiescent current of 100 µA and supports a maximum load current of 10 mA. Packaged in a compact SOT-23-3 format, it is designed for applications requiring stable reference voltages.

Feature Summary

Provides a fixed 1.0V precision reference voltage
Features low temperature drift for stable performance across operating ranges
Designed for space-constrained surface-mount applications

Applications

Precision analog-to-digital converter (ADC) references
Data acquisition systems requiring stable voltage baselines
Portable battery-powered instrumentation

Procurement Notes

Verify the specific suffix 'P' against the official MPS datasheet to confirm package type and tape/reel specifications. Ensure the component meets RoHS compliance requirements for your assembly process. Cross-reference the manufacturer part number with authorized distributor catalogs to confirm availability and authenticity before procurement.

Selection Notes

Select this component when a fixed 1.0V reference is required with 1% initial accuracy. Consider the 45 PPM/°C temperature coefficient for thermal stability needs. Evaluate the 100 µA quiescent current against power budget constraints. Ensure the SOT-23-3 package fits the PCB layout constraints.

Part Context

The MP8200 series includes various shunt voltage references with different output voltages and accuracies. The MP8200DT-LF-P specifically denotes the fixed 1.0V variant in the SOT-23-3 package. It belongs to the broader PMIC category under voltage references, offering alternatives like adjustable versions or higher precision models within the same family.
