MPL-AL6050-1R2

Fixed Inductors Overview

The MPL-AL6050-1R2 is a surface-mount power inductor from the Monolithic Power Systems MPL-AL series. It features a molded construction with an inductance of 1.2 µH. The component supports a maximum DC current rating of 14.6 A and a saturation current of 20 A. Its maximum DC resistance is 5.3 mΩ. The device operates within a temperature range of -40°C to +125°C and complies with RoHS standards.

Fixed Inductors Feature Summary

• Molded construction for low resistance performance
• High current handling capability up to 20 A saturation
• Surface mount design suitable for automated assembly

Fixed Inductors Applications

• DC-DC converter output filtering
• Point-of-load (POL) power stages
• General-purpose power supply circuits

Fixed Inductors Procurement Notes

Verify the specific part number MPL-AL6050-1R2 against official Monolithic Power Systems documentation to confirm electrical parameters and mechanical dimensions. Ensure compatibility with RoHS compliance requirements for the target application. Cross-reference datasheet specifications for thermal management and current ratings prior to integration into final designs.

Fixed Inductors Selection Notes

Select this component based on the required 1.2 µH inductance and the 6050 package size constraints. Evaluate the 14.6 A continuous current and 20 A saturation limits against the circuit's peak load requirements. Consider the 5.3 mΩ DCR impact on efficiency and thermal performance within the specified operating temperature range.

Fixed Inductors Part Context

This component belongs to the MPL-AL series of low-resistance molded power inductors by Monolithic Power Systems. The series includes various sizes such as 4020, 5030, 5050, 6050, and 6060. The MPL-AL6050-1R2 specifically utilizes the 6050 footprint, offering a balance between high current capacity and compact board space.

Fixed Inductors Replacement Considerations

Consult official MPS documentation for direct substitutes or pin-compatible alternatives within the MPL-AL family. Verify that any replacement matches the 1.2 µH inductance, 6050 dimensions, and current ratings.
