MPQ1922GVE-AEC1-Z

$4.33

Description：IC GATE DRVR HALF-BRIDGE 22QFN
Series：-
Mfr：Monolithic Power Systems Inc.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:c66574f5aef2 Category: Gate Drivers Brand: Monolithic Power Systems Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC GATE DRVR HALF-BRIDGE 22QFN
Series：-
Mfr：Monolithic Power Systems Inc.
Package：Tape & Reel (TR),Cut Tape (CT)
Driven Configuration：Half-Bridge
Channel Type：Independent
Number of Drivers：2
Gate Type：MOSFET (N-Channel)
Voltage - Supply：0V ~ 100V
Logic Voltage - VIL, VIH：0.8V, 2.2V
Current - Peak Output (Source, Sink)：3A, 4A
Input Type：Non-Inverting
Rise / Fall Time (Typ)：-
Operating Temperature：-40°C ~ 165°C (TJ)
Mounting Type：Surface Mount, Wettable Flank
Package / Case：22-VFQFN Exposed Pad
Supplier Device Package：22-QFN (4x5)
Grade：-
Qualification：-
High Side Voltage - Max (Bootstrap)：115 V

Download product information

MPQ1922GVE-AEC1-Z

Overview

The MPQ1922GVE-AEC1-Z is a high-frequency half-bridge gate driver IC from Monolithic Power Systems, qualified to AEC-Q100 standards for automotive reliability. It supports an input voltage range of 5V to 60V and delivers peak output currents of 3A source and 4A sink. The device operates within a junction temperature range of -40°C to 165°C and is housed in a 22-QFN (4x5 mm) package with wettable flanks for enhanced inspection.

Feature Summary

Automotive-grade qualification ensuring high reliability for demanding environments
High-frequency operation capability for efficient power system design
Robust drive strength with asymmetric source and sink current capabilities

Applications

Brushless DC motor drives
Brushed DC motor control systems
General-purpose half-bridge switching applications

Procurement Notes

Verify the specific suffix 'Z' indicates lead-free status and RoHS compliance as per manufacturer declarations. Confirm the package variant includes wettable flanks if automated optical inspection is required. Ensure the ordering quantity matches the standard reel packaging specifications provided by the distributor.

Selection Notes

Select this component when a compact, automotive-rated half-bridge driver is needed for motor control or isolated switching. The 22-QFN package offers a small footprint suitable for space-constrained designs. Verify that the required peak current aligns with the 3A source and 4A sink ratings for the specific load conditions.

Part Context

This part belongs to the MPQ1922 series of gate drivers designed for high-efficiency power conversion. It complements other MPS PMIC solutions by providing precise control for external MOSFETs in synchronous rectification or half-bridge topologies, integrating protection features typical of modern automotive power management ICs.
