MPQ6526GU-AEC1-P

Overview

The MPQ6526GU-AEC1-P is a hex half-bridge motor driver with serial input control, qualified to AEC-Q100 standards. It features an output current of 900 mA and operates from a supply voltage range of 7 V to 28 V. The device has a quiescent operating supply current of 2.75 mA and functions within a temperature range of -40 °C to +150 °C. It is housed in a QFN-24 package.

Feature Summary

• Hex half-bridge configuration for multi-motor or complex load driving
• Serial interface for simplified control signal integration
• AEC-Q100 automotive qualification for reliability
• High junction temperature rating up to 150 °C

Applications

• Automotive seat adjustment systems
• Power window actuators
• HVAC fan control modules
• Industrial motion control applications

Procurement Notes

Verify the specific suffix 'GU-AEC1-P' against the manufacturer's official datasheet to confirm package type and tape-and-reel specifications. Ensure that the AEC-Q100 qualification status matches the project requirements. Cross-reference the QFN-24 footprint dimensions with the design layout before finalizing procurement orders.

Selection Notes

Select this component when a single IC solution is required to drive multiple half-bridge loads via a serial interface. The high operating temperature range makes it suitable for harsh environments. Consider the 900 mA output capability relative to the load requirements. Verify compatibility with the system's serial communication protocol and voltage levels.

Part Context

This part belongs to the Monolithic Power Systems MPQ6526 family of motor drivers. It is designed for automotive and industrial applications requiring reliable motor control. The series offers various packaging and qualification options to suit different design constraints and environmental conditions.

Replacement Considerations

MPQ6526GR-AEC1-Z is listed as a parameter-equivalent substitute by distributors.
