Product Detailed Parameters
- Description：POWER MOD BRIDGE THY 3PH M5
- Series：-
- Mfr：Microsemi Corporation
- Package：Bulk
- Structure：Bridge, 3-Phase - SCRs/Diodes
- Number of SCRs, Diodes：1 SCR, 6 Diodes
- Voltage - Off State：1.6 kV
- Current - On State (It (AV)) (Max)：150 A
- Current - On State (It (RMS)) (Max)：-
- Current - Non Rep. Surge 50, 60Hz (Itsm)：1500A @ 50Hz
- Operating Temperature：-
- Mounting Type：Chassis Mount
- Package / Case：M5 Module
- Voltage - Gate Trigger (Vgt) (Max)：3 V
- Current - Gate Trigger (Igt) (Max)：150 mA
- Current - Hold (Ih) (Max)：-
- Grade：-
- Qualification：-
Download product information
Overview
The MSDT150-16 is a silicon controlled rectifier module manufactured by Microsemi Corporation. It features a single element configuration with a maximum repetitive peak reverse voltage of 1600V and an on-state RMS current rating of 235.5A. The device is housed in the M-5 package, which utilizes a seven-pin case design for robust industrial integration.
Feature Summary
- Integrated three-phase bridge and thyristor topology within a single compact module
- High-voltage blocking capability suitable for demanding power conversion environments
- Robust mechanical construction designed for reliable operation in industrial settings
Applications
- Industrial equipment power control systems
- Embedded electronics requiring high-power DC-to-AC conversion
- Three-phase motor drive applications
Procurement Notes
Verify component authenticity through authorized channels as this part is discontinued. Confirm package integrity and pin alignment against original specifications. Request detailed test reports to validate performance parameters prior to integration into critical systems.
Selection Notes
Evaluate thermal management requirements carefully due to the high current ratings inherent in this module type. Ensure that the driving circuitry can support the gate trigger characteristics specified for the M-5 package family. Consider physical mounting constraints associated with the seven-pin configuration during system design.
Part Context
This component belongs to Microsemi's series of power semiconductor modules designed for heavy-duty applications. The MSDT150-16 represents a specific variant within the broader product line, offering integrated functionality for three-phase systems. It serves as a key building block for high-power electronic converters.
Replacement Considerations
Public confirmed substitute part numbers are not available. As the manufacturer has scheduled this item for obsolescence, engineers must identify alternative components based on matching electrical specifications and mechanical footprint compatibility.
