MSP430FR2153TPT

Microcontrollers Overview

The MSP430FR2153TPT is a 16-bit microcontroller from the Texas Instruments MSP430 family, housed in an LQFP-48 package. It features a maximum clock frequency of 24 MHz and operates within a supply voltage range of 1.8 V to 3.6 V. The device includes 16 kB of FRAM program memory and 2 kB of SRAM data memory. It provides 44 I/O pins and supports interfaces including SPI, I2C, and UART. The integrated analog section comprises an 8-channel, 12-bit ADC. Operating temperatures range from -40°C to +105°C.

Microcontrollers Feature Summary

• Integrates non-volatile FRAM for reliable data retention without charge pump overhead
• Includes high-resolution 12-bit analog-to-digital converter with multiple input channels
• Supports standard serial communication protocols via dedicated hardware peripherals

Microcontrollers Applications

• Industrial sensor nodes requiring robust data logging
• Smart metering applications with strict power constraints
• Embedded control systems operating in extended temperature environments

Microcontrollers Procurement Notes

Verify the specific suffix 'TPT' corresponds to the LQFP-48 tray packaging configuration when ordering. Confirm that the required pin count and peripheral set align with the target design specifications. Ensure compatibility with the intended development tools and programming interfaces provided by the manufacturer for this specific part number variant.

Microcontrollers Selection Notes

Select this component when a balance of moderate memory capacity and high-speed processing is required within a compact surface-mount footprint. The inclusion of FRAM eliminates write endurance limitations associated with traditional flash. Evaluate the 24 MHz performance against system timing requirements to ensure adequate processing headroom for real-time tasks.

Microcontrollers Part Context

This model belongs to the MSP430FR2xxx series, designed for low-power mixed-signal applications. It shares architectural similarities with other devices in the family but offers distinct memory sizes and package options. The FRAM technology differentiates it from older flash-based counterparts by providing faster write speeds and higher endurance.

Microcontrollers Replacement Considerations

Consult official substitution guides for equivalent parts within the MSP430FR2xxx series. Verify pin compatibility and memory size differences before replacing existing designs with alternative package variants or higher/lower specification members of the same product family.
