MSPD1012-H50

Overview

The MSPD1012-H50 is a sampling phase detector manufactured by MACOM Technology Solutions. It operates within a frequency range of 50MHz to 12.5GHz and utilizes an H50 surface-mount package. This component is designed for general-purpose RF integrated circuit applications requiring precise phase detection capabilities in high-frequency systems.

Feature Summary

• Sampling architecture for accurate phase measurement
• High-frequency operation up to 12.5GHz
• Surface-mount design for compact integration

Applications

• General purpose RF integrated circuits
• Wireless communication systems
• Test and instrumentation equipment

Procurement Notes

Verify the specific H50 package variant against your PCB footprint requirements. Confirm that the 50MHz to 12.5GHz operational range aligns with your system's frequency specifications. Ensure compatibility with MACOM's hybrid manufacturing process standards for reliable performance in your target application environment.

Selection Notes

Select this component when a sampling phase detector is required for frequencies extending to 12.5GHz. The H50 surface-mount package facilitates automated assembly and space-constrained designs. Consider the general-purpose nature of the device for broad RF system integration needs without specialized custom requirements.

Part Context

This part belongs to MACOM's MSPD series of sampling phase detectors, which are manufactured using a proven hybrid process. The series includes variants like the MSPD1012-122, offering medium barrier characteristics. These components are engineered for reliability in demanding RF environments, supporting various wireless and industrial applications through standardized surface-mount packaging solutions.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult MACOM directly for current equivalent or alternative product recommendations based on specific electrical and mechanical requirements.
