MSS1048-154KLC

$2.49

Description：FIXED IND 150UH 1.33A 330MOHM SM
Series：MSS1048
Mfr：Coilcraft
Package：Strip

SKU:f4b3f57a0332 Category: Fixed Inductors Brand: Coilcraft

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MSS1048-154KLC is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Coilcraft. Its product description is FIXED IND 150UH 1.33A 330MOHM SM. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for MSS1048-154KLC

Description：FIXED IND 150UH 1.33A 330MOHM SM
Series：MSS1048
Mfr：Coilcraft
Package：Strip
Type：Drum Core
Material - Core：Ferrite
Inductance：150 µH
Tolerance：±10%
Current Rating (Amps)：1.33 A
Current - Saturation (Isat)：790mA
Shielding：Shielded
DC Resistance (DCR)：330mOhm Max
Q @ Freq：-
Frequency - Self Resonant：5MHz
Ratings：AEC-Q200
Operating Temperature：-40°C ~ 85°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.402" L x 0.394" W (10.20mm x 10.00mm)
Height - Seated (Max)：0.201" (5.10mm)
Features：-

Fixed Inductors datasheet and documents for MSS1048-154KLC

MSS1048-154KLC

Fixed Inductors Overview

The Coilcraft MSS1048-154KLC is a fixed surface-mount power inductor from the MSS1048 series, designed for automotive and industrial applications. It features a ferrite drum core with magnetic shielding to minimize electromagnetic interference. The component has an inductance of 150 µH with a tolerance of ±10%. It supports a maximum DC current of 1.33 A and exhibits a maximum DC resistance of 0.33 Ω. The self-resonant frequency is specified at 5.00 MHz. The package dimensions are 10 mm x 10.2 mm with a height of 4.8 mm.

Fixed Inductors Feature Summary

Magnetic shielding reduces electromagnetic interference for sensitive circuits
Ferrite drum core construction provides stable inductance characteristics
Automotive-grade reliability suitable for harsh environments

Fixed Inductors Applications

Automotive electronics systems
Industrial power supply filtering
DC-DC converter output stages

Fixed Inductors Procurement Notes

Verify the specific suffix KLC against the manufacturer's official datasheet to confirm tolerance and packaging details. Ensure the selected variant matches the required inductance value and current ratings for the target circuit design. Cross-reference the part number with authorized distributors to confirm availability and authenticity before procurement.

Fixed Inductors Selection Notes

Select this inductor when a compact shielded solution with 150 µH inductance is required. Consider the 1.33 A current rating and 0.33 Ω DCR for efficiency calculations. The 10mm footprint fits standard SMD layouts. Verify thermal performance under load conditions to ensure operation within the specified temperature range.

Fixed Inductors Part Context

The MSS1048 series consists of shielded power inductors manufactured by Coilcraft. These components are characterized by their low profile and high saturation current capabilities. The series is widely used in applications requiring reliable performance in space-constrained designs, particularly within the automotive sector where AEC-Q200 compliance is often critical.
