MSS1260-563MLD

Fixed Inductors Overview

The Coilcraft MSS1260-563MLD is a shielded surface-mount power inductor from the MSS1260 series, designed for high-density mounting. It features a ferrite core and offers an inductance of 56 µH with a tolerance of ±20%. The component supports a maximum DC current of 2.4 A and has a maximum DC resistance of 89 mΩ. It is qualified to AEC-Q200 standards for automotive applications. The physical dimensions are 12.3 mm in length, 12.3 mm in width, and 6 mm in height, housed in a 4848 package.

Fixed Inductors Feature Summary

• Magnetic shielding reduces electromagnetic interference for reliable operation in dense circuits.
• Flat top construction ensures reliable pick-and-place handling during automated assembly.
• AEC-Q200 qualification confirms suitability for demanding automotive electronic environments.

Fixed Inductors Applications

• Automotive DC-DC converters
• Portable electronic devices requiring low cost and high reliability
• LCD panel power supplies

Fixed Inductors Procurement Notes

Verify the specific suffix 'MLD' against official Coilcraft documentation to confirm tape and reel packaging specifications. Ensure the part number matches the exact inductance value of 56 µH and current ratings required by the design. Cross-reference the AEC-Q200 certification status directly with the manufacturer's latest datasheet to confirm compliance for automotive use cases.

Fixed Inductors Selection Notes

Select this component when a shielded inductor with a 56 µH nominal value is required for space-constrained designs. The 4848 footprint allows for high-density mounting compared to larger packages. Consider the 2.4 A saturation current limit and 89 mΩ DCR for efficiency calculations in DC-DC converter topologies where thermal management is critical.

Fixed Inductors Part Context

The MSS1260 series provides high inductance and efficiency in a low-profile format. This specific model utilizes a drum core structure within a shielded enclosure. The series is engineered for applications where low cost and high reliability are critical, offering standard values alongside custom-engineered options for specific application needs.

Fixed Inductors Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with alternative components by matching the 56 µH inductance, 2.4 A current rating, 4848 footprint, and AEC-Q200 qualification requirements.
