MSS7341T-823MLD

$2.13

Description：FIXED IND 82UH 1.25A 290MOHM SM
Series：MSS7341T
Mfr：Coilcraft
Package：Strip

SKU:8c1821114e5f Category: Fixed Inductors Brand: Coilcraft

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MSS7341T-823MLD is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Coilcraft. Its product description is FIXED IND 82UH 1.25A 290MOHM SM. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for MSS7341T-823MLD

Description：FIXED IND 82UH 1.25A 290MOHM SM
Series：MSS7341T
Mfr：Coilcraft
Package：Strip
Type：Drum Core
Material - Core：Ferrite
Inductance：82 µH
Tolerance：±20%
Current Rating (Amps)：1.25 A
Current - Saturation (Isat)：570mA
Shielding：Shielded
DC Resistance (DCR)：290mOhm Max
Q @ Freq：-
Frequency - Self Resonant：8.5MHz
Ratings：AEC-Q200
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.287" L x 0.287" W (7.30mm x 7.30mm)
Height - Seated (Max)：0.161" (4.10mm)
Features：-

Fixed Inductors datasheet and documents for MSS7341T-823MLD

MSS7341T-823MLD

Fixed Inductors Overview

The Coilcraft MSS7341T-823MLD is a shielded surface-mount power inductor from the MSS7341T series, designed for high ambient temperatures up to 125°C. It features an 82 µH nominal inductance with a tolerance of ±20%. The component utilizes a ferrite drum core construction and is AEC-Q200 Grade 1 qualified. Key electrical parameters include a maximum DC resistance of 124 mΩ and a self-resonant frequency of 27 MHz. The physical dimensions are 7.3 mm in length, 7.3 mm in width, and 4.1 mm in height.

Fixed Inductors Feature Summary

Shielded surface-mount design for reduced electromagnetic interference
AEC-Q200 Grade 1 qualification for automotive reliability
High thermal stability supporting operation up to 125°C

Fixed Inductors Applications

Automotive power supply circuits
DC-DC converter filtering
General purpose power inductor applications

Fixed Inductors Procurement Notes

Verify the specific suffix MLD against official Coilcraft documentation to confirm lead frame material and plating specifications. Ensure the selected variant meets the required AEC-Q200 Grade 1 standards for your target application environment. Cross-reference the datasheet for precise saturation current ratings under your operating temperature conditions before finalizing procurement.

Fixed Inductors Selection Notes

Select this component when a shielded inductor with high current handling and low DC resistance is required in a compact 2929 package. The MSS7341T series offers excellent performance in wide inductance ranges. Consider the 125°C operating temperature rating for high-heat environments where standard components may fail. Verify that the 82 µH value aligns with the circuit's switching frequency and ripple current requirements.

Fixed Inductors Part Context

The MSS7341T series represents Coilcraft's line of shielded surface-mount power inductors engineered for demanding applications. These components are distinguished by their ferrite drum core construction and robust shielding capabilities. The series is widely recognized for its ability to maintain performance characteristics across a broad spectrum of inductance values while adhering to strict automotive quality standards.
