Product Detailed Parameters
- Description：IC MOTOR DRIVER 2V-14V 10MSOP
- Series：-
- Mfr：Microchip Technology
- Package：Tape & Reel (TR)
- Motor Type - Stepper：-
- Motor Type - AC, DC：Brushless DC (BLDC)
- Function：Driver - Fully Integrated, Control and Power Stage
- Output Configuration：Half Bridge (3)
- Interface：PWM
- Technology：DMOS
- Step Resolution：-
- Applications：Fan Motor Driver
- Current - Output：500mA
- Voltage - Supply：2V ~ 14V
- Voltage - Load：2V ~ 14V
- Operating Temperature：-30°C ~ 150°C (TJ)
- Mounting Type：Surface Mount
- Package / Case：10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
- Supplier Device Package：10-MSOP
- Grade：-
- Qualification：-
Download product information
Overview
The MTD6501D-LC1 is a three-phase full-wave fan motor driver manufactured by Microchip Technology. It operates on a single supply voltage ranging from 2 V to 14 V with a maximum operating current of 10 mA. The device features an output current capability of 500 mA and utilizes DMOS technology for efficient power handling. Designed for surface-mount installation, it is housed in a 10-pin MSOP package. The component supports an operating temperature range from -10 °C to 95 °C and is compliant with RoHS standards.
Feature Summary
- Integrates control logic and power stage for brushless DC fan motors
- Supports PWM interface for speed control
- Operates within a wide voltage range of 2 V to 14 V
Applications
- Fan motor drivers
- Brushless DC (BLDC) motor control
- Motion control systems
Procurement Notes
Verify the specific suffix LC1 against the official datasheet to confirm pinout and thermal characteristics. Ensure the ordering quantity aligns with the manufacturer's tape and reel packaging requirements. Confirm that the application environment remains within the specified -10 °C to 95 °C operating temperature range to maintain reliability.
Selection Notes
Select this component when a compact solution for three-phase BLDC fan control is required. The MSOP-10 package offers a small footprint suitable for space-constrained designs. Verify that the 500 mA output current meets the load requirements and that the 2 V to 14 V supply range matches the system power architecture.
Part Context
This part belongs to the MTD6501 family of motor controllers from Microchip Technology. The family includes variants such as MTD6501C and MTD6501G, which may differ in package type or thermal performance. These devices are categorized under PMIC and Motor/ Motion Controllers, designed specifically for cooling applications requiring integrated drive capabilities.
Replacement Considerations
Consult the official Microchip selector guide for direct substitutes within the MTD6501 series. Verify compatibility regarding package dimensions and electrical specifications before replacing.
