MTS62C19A-HS105

Overview

The MTS62C19A-HS105 is a dual full-bridge PWM motor driver manufactured by Microchip Technology. It supports bipolar stepper motors with selectable resolution steps of 1, 1/2, 1/4, and 1/8. The device operates on a supply voltage range of 4.5V to 5.5V and handles load voltages from 10V to 40V. It features an output current of 750mA and utilizes a CMOS open/close interface. Packaged in a 24-SOP format, it is designed for surface mount installation.

Feature Summary

• Integrates full control and power stages for complete motor driving functionality
• Supports multiple stepping resolutions including half, quarter, and eighth steps
• Designed for automotive grade reliability and operation

Applications

• Stepper motor driver development
• Automotive motion control systems
• Bipolar stepper motor applications

Procurement Notes

Verify the specific suffix HS105 against the official datasheet to confirm package type and temperature rating. Ensure compatibility with the mikroBUS Click platform if using the MIKROE-2912 adapter board. Confirm RoHS compliance status prior to integration into final products.

Selection Notes

Select this component for applications requiring integrated bipolar stepper motor control with high current capability. Consider the 24-SOP package size for PCB layout constraints. Verify that the operating temperature range meets the environmental requirements of the target application.

Part Context

This part belongs to the MTS62C19 series of motor drivers. It is often associated with the MIKROE-2912 evaluation board from MikroElektronika for rapid prototyping. The device serves as a core component for developing stepper motor solutions within the broader Microchip technology ecosystem.

Replacement Considerations

Check for PCN notifications regarding product changes or cancellations. No direct substitute part numbers are publicly confirmed in the provided documentation.
