MTSW-101-21-T-S-750-RA

Headers, Male Pins Overview

The MTSW-101-21-T-S-750-RA is a single-row male pin header from the Samtec Flex Stack MTSW series. It features a 2.54 mm (0.100 inch) pitch and utilizes through-hole solder termination with a right-angle mounting style. The connector includes 1 position, phosphor bronze contacts with matte tin plating, and a black polyester insulator. It supports board-to-board and cable applications within an operating temperature range of -55°C to +105°C.

Headers, Male Pins Feature Summary

• Flex Stack design allows for modified post heights and body positions in precise increments
• Variable height terminal strip accommodates diverse stacking requirements
• Right-angle orientation facilitates compact board layout configurations

Headers, Male Pins Applications

• Board-to-Board interconnections
• Cable connections
• Board stacking applications

Headers, Male Pins Procurement Notes

Verify the specific contact length suffix against mechanical constraints before ordering. Confirm that the right-angle orientation aligns with the target PCB footprint. Ensure the matte tin plating meets environmental compliance requirements for the intended application. Cross-reference the official datasheet for accurate dimensional tolerances.

Headers, Male Pins Selection Notes

Select this component when a single-row, right-angle connection is required. The variable post height capability addresses non-standard spacing needs. Verify that the through-hole termination method matches the manufacturing process. Consider the operating temperature limits relative to the environment.

Headers, Male Pins Part Context

This part belongs to the MTSW series, which offers modified .025 inch square posts. The series provides extensive stacking flexibility by allowing custom post heights. It serves as a variation on the standard TSW header strip, enabling tailored solutions for specific mechanical interfaces without requiring custom tooling.

Headers, Male Pins Replacement Considerations

Consult the official Samtec cross-reference guide for verified substitutes. Ensure any replacement maintains the same pitch, row count, and mounting angle. Verify compatibility with existing mating connectors.
