MURHF860CTG

Description：DIODE ARRAY GP 600V 4A TO-220FP
Series：SWITCHMODE™

SKU:3429acad9b26 Category: Diode Arrays Brand: onsemi

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：DIODE ARRAY GP 600V 4A TO-220FP
Series：SWITCHMODE™
Mfr：onsemi
Package：Tube
Diode Configuration：1 Pair Common Cathode
Technology：Standard
Voltage - DC Reverse (Vr) (Max)：600 V
Current - Average Rectified (Io) (per Diode)：4A
Voltage - Forward (Vf) (Max) @ If：2.8 V @ 4 A
Speed：Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)：35 ns
Current - Reverse Leakage @ Vr：10 µA @ 600 V
Operating Temperature - Junction：-65°C ~ 150°C
Mounting Type：Through Hole
Package / Case：TO-220-3 Full Pack
Supplier Device Package：TO-220FP
Grade：-
Qualification：-

Download product information

MURHF860CTG

Overview

The MURHF860CTG is an ultrafast rectifier featuring a common cathode configuration with two diodes. It supports a peak repetitive reverse voltage of 600 V and delivers a total average rectified forward current of 8 A (4 A per leg). The device exhibits a maximum reverse recovery time of 35 ns and a peak non-repetitive surge current rating of 100 A. It operates within a junction temperature range of -65°C to +150°C and utilizes a TO-220FP package.

Feature Summary

Ultrafast 35 nanosecond recovery times for high-speed switching applications
Electrically isolated construction eliminating the need for additional isolation hardware
High voltage capability up to 600 V with low leakage current specifications at elevated temperatures

Applications

Switching power supplies
Inverters
Free wheeling diodes

Procurement Notes

Verify the specific ordering suffix 'G' confirms the lead-free package status as documented in the datasheet. Confirm the package style matches the required TO-220 Fullpak dimensions and pinout configuration for your PCB layout. Ensure thermal management strategies account for the specified junction-to-case thermal resistance values under expected operating loads.

Selection Notes

Select this component when designs require fast recovery characteristics combined with high voltage blocking capabilities. The dual common cathode arrangement allows for efficient bridge or center-tapped configurations. Evaluate thermal performance against the 4.1 °C/W junction-to-case resistance to ensure reliable operation within the 150°C maximum junction temperature limit.

Part Context

This device belongs to the MURHF series of Switch-mode power rectifiers manufactured by onsemi. These components are engineered specifically for high-frequency power conversion environments where rapid switching transitions and robust voltage handling are critical requirements for system efficiency and reliability.
