Product Detailed Parameters
- Description：15W SINGLE-COIL CONSUMER STAND
- Series：-
- Mfr：NXP USA Inc.
- Package：Bulk,Tray
- Applications：General Purpose
- Current - Supply：-
- Voltage - Supply：2.7V ~ 3.6V
- Operating Temperature：-40°C ~ 105°C
- Mounting Type：Surface Mount, Wettable Flank
- Package / Case：32-VFQFN Exposed Pad
- Supplier Device Package：32-HVQFN (5x5)
- Grade：-
- Qualification：-
Download product information
Overview
The MWCT1011CFM is a wireless charging transmitter integrated circuit designed for 15W single-coil consumer applications. It operates within a supply voltage range of 2.7V to 3.6V and supports the WPC standard. The device is housed in a 32-HVQFN (5x5) package with exposed pad mounting. It functions as a general-purpose PMIC suitable for implementing complete controller functionality in wireless charging solutions.
Feature Summary
- Provides complete controller functionality for wireless charging transmitter implementations
- Supports single-coil consumer application architectures
- Complies with Wireless Power Consortium (WPC) standards
Applications
- Wireless charging transmitters
- Consumer electronics charging bases
- Single-coil power transfer systems
Procurement Notes
Verify component authenticity through authorized NXP channels. Confirm RoHS3 compliance status prior to integration. Ensure moisture sensitivity level 3 handling protocols are followed during storage and assembly processes. Validate package marking against official datasheet specifications to prevent counterfeit substitution.
Selection Notes
Select this IC for designs requiring standardized 15W single-coil transmission. Ensure input power supplies remain within the 2.7V to 3.6V operational window. Verify thermal management capabilities align with the HVQFN package constraints. Confirm compatibility with required external low-voltage MOSFETs for optimal system performance.
Part Context
This component belongs to the MWCT1x1x series from NXP Semiconductors, originally developed under the Freescale brand. It serves as a dedicated power management solution for wireless power transfer infrastructure. The part integrates essential control logic for efficient energy transmission in compliant consumer devices.
Replacement Considerations
The MWCT1012CFM is documented as an alternative transmitter controller within the same product family. Verify pinout compatibility and firmware requirements before substituting components in existing reference designs.
