MWCT1015SFVMHN

Overview

The MWCT1015SFVMHN is a wireless power transmitter PMIC from NXP Semiconductors, featuring an ARM Cortex-M4F core. It integrates 1 MB of program memory and 128 KB of data RAM, operating at a maximum clock frequency of 112 MHz. The device supports 32-bit data bus width and includes a 12-bit ADC. It offers 89 I/O pins within a BGA-100 package. Operating voltage ranges from 2.7 V to 5.5 V, with a functional temperature range of -40°C to 105°C.

Feature Summary

• Integrates an ARM Cortex-M4F processor core for embedded control
• Supports in-field programming capabilities
• Designed specifically for wireless power transmission applications

Applications

• Automotive wireless charging systems
• Wireless power transmitters
• Embedded control units for power management

Procurement Notes

Verify the exact suffix against official NXP documentation to confirm package type and temperature grade. Ensure compatibility with your PCB footprint and thermal requirements. Confirm RoHS compliance status through the manufacturer's current datasheet. Cross-reference the ordering part number with the specific revision level required for your design.

Selection Notes

Select this component when a combined microcontroller and power management solution is needed for wireless charging. The integrated Cortex-M4F allows for complex protocol handling without external processors. Consider the 100-ball BGA package for space-constrained designs. Evaluate the 112 MHz processing speed against your real-time control latency requirements.

Part Context

This part belongs to the MWCT101xsf series of wireless charging controllers. It combines digital control logic with power stage drivers. The series targets high-efficiency wireless power transfer standards. It replaces older discrete controller solutions by integrating processing and power management functions.

Replacement Considerations

Check NXP's official substitution guide for direct pin-compatible alternatives. Verify if newer revisions offer improved efficiency or additional features. Ensure any substitute maintains the same ARM Cortex-M4F architecture for software compatibility.
