MX25UW12845GXDI00

$2.37

Description：IC FLASH 128MBIT SPI/QUAD 24CBGA
Series：OctaBus™
Mfr：Macronix
Package：Tray

SKU:a44db64c5cec Category: Memory IC Brand: Macronix

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MX25UW12845GXDI00 is listed in the Memory IC range at ChipApex. The manufacturer field lists Macronix. Its product description is IC FLASH 128MBIT SPI/QUAD 24CBGA. Review the specifications below when checking this part for your BOM.

Memory IC specifications for MX25UW12845GXDI00

Description：IC FLASH 128MBIT SPI/QUAD 24CBGA
Series：OctaBus™
Mfr：Macronix
Package：Tray
Memory Type：Non-Volatile
Memory Format：FLASH
Technology：FLASH - NOR (SLC)
Memory Size：128Mbit
Memory Organization：16M x 8, 128M x 1
Memory Interface：SPI - Octal I/O, DTR
Clock Frequency：200 MHz
Write Cycle Time - Word, Page：1.5ms
Voltage - Supply：1.65V ~ 2V
Operating Temperature：-40°C ~ 85°C (TA)
Mounting Type：Surface Mount
Package / Case：24-TBGA, CSPBGA
Supplier Device Package：24-CSPBGA (6x8)
Access Time：4.55 ns
Grade：-
Qualification：-

Memory IC datasheet and documents for MX25UW12845GXDI00

MX25UW12845GXDI00

Memory IC Overview

The MX25UW12845GXDI00 is a 128 Mbit Serial NOR Flash memory device manufactured by Macronix. It operates within a supply voltage range of 1.65 V to 2 V and supports an SPI interface with a maximum clock frequency of 200 MHz. The memory organization is specified as 16 M x 8 bits, utilizing an 8-bit data bus width with synchronous timing. The component is housed in a TFBGA-24 package suitable for surface mount technology. It functions reliably across an industrial temperature range from -40°C to +85°C.

Memory IC Feature Summary

Supports Read While Write (RWW) operations for simultaneous code execution and data storage updates
Features high-speed serial peripheral interface compatible with standard SPI protocols
Designed for low power consumption applications with wide voltage operation range

Memory IC Applications

Firmware storage in embedded systems requiring code execution from flash
Data logging applications in industrial control environments
Boot code storage for microcontroller-based devices

Memory IC Procurement Notes

Verify the specific suffix codes against official Macronix documentation to confirm pinout compatibility and operational specifications. Ensure that the TFBGA-24 package dimensions align with your PCB footprint requirements. Confirm moisture sensitivity level handling procedures during assembly to prevent damage. Cross-reference the manufacturer part number with authorized distributor listings to ensure authenticity and traceability.

Memory IC Selection Notes

Select this component when a 128 Mbit capacity is required with support for read while write functionality. The 200 MHz clock speed makes it suitable for high-performance applications needing fast boot times. The 1.65 V to 2 V voltage range fits low-power designs. Consider the TFBGA-24 package size constraints and thermal dissipation needs for your specific enclosure design.

Memory IC Part Context

This part belongs to the Macronix MX25UW series of Serial NOR Flash memories. The series is characterized by its Read While Write capability, allowing the system to execute code from one block while writing to another. This series targets applications requiring high reliability and performance in compact form factors, commonly used in consumer electronics and industrial equipment.
