MX29GL320EHT2I-70G

$3.33

Description：IC FLASH 32MBIT PARALLEL 56TSOP
Series：MX29GL
Mfr：Macronix
Package：Tray

SKU:34cb55d7989f Category: Memory IC Brand: Macronix

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MX29GL320EHT2I-70G is listed in the Memory IC range at ChipApex. The manufacturer field lists Macronix. Its product description is IC FLASH 32MBIT PARALLEL 56TSOP. Review the specifications below when checking this part for your BOM.

Memory IC specifications for MX29GL320EHT2I-70G

Description：IC FLASH 32MBIT PARALLEL 56TSOP
Series：MX29GL
Mfr：Macronix
Package：Tray
Memory Type：Non-Volatile
Memory Format：FLASH
Technology：FLASH - NOR
Memory Size：32Mbit
Memory Organization：4M x 8
Memory Interface：Parallel
Clock Frequency：-
Write Cycle Time - Word, Page：70ns
Voltage - Supply：2.7V ~ 3.6V
Operating Temperature：-40°C ~ 85°C (TA)
Mounting Type：Surface Mount
Package / Case：56-TFSOP (0.724", 18.40mm Width)
Supplier Device Package：56-TSOP
Access Time：70 ns
Grade：-
Qualification：-

Memory IC datasheet and documents for MX29GL320EHT2I-70G

MX29GL320EHT2I-70G

Memory IC Overview

The MX29GL320EHT2I-70G is a 32Mbit (4,194,304 x 8 or 2,097,152 x 16) NOR flash memory manufactured by Macronix. It operates on a single 2.7V to 3.6V power supply with VI/O tied to VCC. The device features a 70ns access time and supports asynchronous parallel interfaces. It utilizes a 56-pin TSOP package and includes a uniform sector architecture for the H/L variants.

Memory IC Feature Summary

Supports switchable byte (x8) and word (x16) modes via the BYTE# pin.
Includes hardware write protection capabilities through the WP#/ACC input pin.
Features a Ready/Busy output pin for detecting program and erase completion.
Provides sector protection functions including persistent and password protection.

Memory IC Applications

Code storage in embedded systems requiring direct execution.
Firmware storage for industrial control applications.
Data retention in consumer electronics devices.

Memory IC Procurement Notes

Verify the specific suffix 'H' indicates the uniform sector architecture variant distinct from 'T' or 'B'. Confirm the 'I' suffix corresponds to the industrial temperature range specifications. Ensure the datasheet revision matches the required design-in documentation for compliance verification.

Memory IC Selection Notes

Select this component when a 32Mbit capacity with a 70ns access speed is required. The uniform sector architecture of the H variant simplifies block management compared to mixed boot sectors. Verify that the 56-pin TSOP footprint aligns with the PCB layout constraints.

Memory IC Part Context

This part belongs to the MX29GL320E series of 3V-only NOR flash memories. The 'H' designation specifies the uniform sector configuration, while 'T' and 'B' denote top and bottom boot sector architectures respectively within the same family.
