MX7528JP+

Digital To Analog Converters Overview

The MX7528JP+ is a dual-channel, 8-bit digital-to-analog converter manufactured by Analog Devices Inc. under the Maxim Integrated brand. It utilizes an R-2R resistor ladder architecture and features a parallel data interface for input. The device operates within a supply voltage range of 5 V to 15 V for both analog and digital sections. Key performance specifications include a settling time of 350 ns, with maximum integral and differential nonlinearity errors of ±1 LSB. It is housed in a 20-PLCC surface-mount package and supports an operating temperature range from 0°C to +70°C.

Digital To Analog Converters Feature Summary

• Dual independent 8-bit DAC channels with R-2R architecture
• Parallel data interface for direct microcontroller connection
• Low power consumption suitable for battery-operated systems
• Current output configuration requiring external buffering

Digital To Analog Converters Applications

• Portable instrumentation and test equipment
• Battery-powered measurement devices
• Industrial process control loops
• Programmable gain amplifier references

Digital To Analog Converters Procurement Notes

Verify component authenticity through authorized distributors or manufacturer channels due to limited availability status. Confirm RoHS compliance and lead times directly with suppliers as stock levels fluctuate. Ensure packaging integrity matches specified tube quantities during receipt inspection.

Digital To Analog Converters Selection Notes

Select this component when dual-channel precision is required with low power constraints. Compare against serial interface alternatives if pin count reduction is critical. Verify that the unbuffered current output aligns with system requirements for external op-amp integration.

Digital To Analog Converters Part Context

This part belongs to the MX7528 series of multiplying DACs. It shares architectural similarities with other members like the MX7528JN but differs in package type and mounting style. The series is designed for applications demanding moderate speed and high accuracy in compact form factors.

Digital To Analog Converters Replacement Considerations

Direct pin-compatible replacements may include other variants within the MX7528 family such as the MX7528LEWP+. Verify electrical parameters and package dimensions before substitution.
